6. BASIC OPERATION
110
16 VECT
Select the display mode of the VECTOR item. Select the mode before clicking or tapping
the VECTOR item.
VECT / 5BAR /HIST / CIE
(*1)
Shows the normal vector display. You can switch the display
between vector waveform, 5bar, histogram and CIE chromaticity
diagram.
It cannot be arranged with the items below at the same time. If you
want to arrange the items below, delete this item first.
VECTOR
Shows vectors.
5BAR
Switches to the 5-bar display.
HIST
A histogram is displayed.
CIE
The CIE chromaticity diagram display is shown.
17 AUDIO
Select the display mode of the AUDIO item. Select the mode before clicking or tapping
the AUDIO item.
LEVEL BAR + etc. (*1)
This is the normal audio display. The display switches between
Lissajous, surround, meter, and status.
It cannot be arranged with the items below at the same time. If you
want to arrange the items below, delete this item first.
LEVEL BAR
Meters are displayed.
LISSAJOU
Lissajous curves are displayed.
STATUS
Shows the status.
SURROUND
Surround waveforms are displayed.
This item will not be displayed correctly when embedded audio is
being measured in simul mode.
