I SERVICE MODE > 8. CS Remote
I-27
▪ At the first time that the main power is turned ON (reboot) after importing the CSRC server information under [Service Mode]
-> [Machine Update Settings] -> [Machine Auto Update Setting] -> [Machine Import Setting].
Setting value Default setting
Set
Unset
○
8.2Software SW setting for Remote Care
8.2.1List of software SW for CS Remote Care
SW No. Functions Ref. page
01 • Dial Mode, Line for send only, Baud rate “ I.8.2.2 SW No. 01”
02 • Emergency transmission, Date specified transmission, Call parts replace date,
Call drum replace date, Call regular service date (PM), Auto call on the IC Life,
Auto call of the IR shortage, Auto call on the zero reset of the fixed parts
replacement
“ I.8.2.3 SW No. 02”
03 • Trouble display setting, Auto call on the toner empty, Auto call on the waste
toner bottle full
“ I.8.2.4 SW No. 03”
04 • CS Remote Care communication mode “ I.8.2.5 SW No. 04”
05 • Modem redial interval “ I.8.2.6 SW No. 05”
06 • Modem redial times “ I.8.2.7 SW No. 06”
07 • Redial for response time out “ I.8.2.8 SW No. 07”
08 • Retransmission interval on E-Mail/http delivery error “ I.8.2.9 SW No. 08”
09 • Retransmission times on E-Mail/http delivery error “ I.8.2.10 SW No. 09”
10 • Time zone settings “ I.8.2.11 SW No. 10”
11 • Timer 1 RING reception -> CONNECT reception “ I.8.2.12 SW No. 11”
12 • Timer 2 Dial request completed -> CONNECT reception “ I.8.2.13 SW No. 12”
13 • Reservation -
14 • Timer 4 Line connection -> Start request telegram delivery “ I.8.2.14 SW No. 14”
15 • Timer 5 Wait time for other side’s response “ I.8.2.15 SW No. 15”
16 • Reservation -
17 • Reservation -
18 • Attention display
To set whether to give the alarm display when using the modem but the power
for the modem is OFF.
“ I.8.2.16 SW No. 18”
19 • Reservation -
20 • Reservation -
21 • Transmission of paper-based misfeed frequent occurrence warning,
Transmission of original-based misfeed frequent occurrence warning, Automatic
transmission of chronological misfeed data at the time of transmission of misfeed
frequent occurrence warning
“ I.8.2.17 SW No. 21”
22 • Paper-based misfeed frequent occurrence threshold value “ I.8.2.18 SW No. 22”
23 • Original-based misfeed frequent occurrence threshold value “ I.8.2.19 SW No. 23”
24
:
40
• Reservation -
8.2.2SW No. 01
Default
Setting value Bit
7 6 5 4 3 2 1 0
Bit Assignment 1 0 0 0 0 0 0 1
HEX
Assignment
81
Functions
Bit Setting item Setting Description
0 1
7 Baud rate 0110 9600 bps
6 0111 19.2 bps
5 1000 38.4 bps
4 Others Not available
3 Reservation
Y119930-3
Service Manual
