d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-119
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
Reception MSLT
ability
000F000B 000F002B 000F004B 000F006B 7-0 T3.85 or 200*100 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
000F000C 000F002C 000F004C 000F006C 7-0 T7.7 or 200*200 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
000F000D 000F002D 000F004D 000F006D 7-0 T11.55 or 300*300 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
000F000E 000F002E 000F004E 000F006E 7-0 T15.4 or 400*400 dpi or
600*600 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
Reception ECM
ability
000F000F 000F002F 000F004F 000F006F 7-1 - - 00000001
0 ECM reception capability
0: OFF
1: ON
ON
Reception protocol
ability
000F0010 000F0030 000F0050 000F0070 7-6 - - 00111001
5 FAX-CSRC (Line 1 only)
○
4 V.8/V.34
○
3 DIAG (Line 1 only)
○
2-1 - -
0 G3S
○
Reception option
frame ability
000F0011 000F0031 000F0051 000F0071 7-5 - - 00000111
4 (BFT)
×
3 (BTM)
×
2 PWD
○
1 (SEP)
○
0 SUB
○
16.12.7HP setting
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
Transmission main
scan line resolution
instruction
00100000 00100020 00100040 00100060 7 400 dpi
×
00100010
6 300 dpi
×
5 200 dpi
○
4 - -
3 16 pels/mm
×
2 - -
1 8 pels/mm
0 - -
00100001 00100021 00100041 00100061 7-3 - - 00000001
2 (1200 dpi)
×
1 (800 dpi)
×
0 600 dpi
○
Transmission sub
scanning resolution
instruction
00100002 00100022 00100042 00100062 7 400 dpi
×
00010001
6 300 dpi
×
5 200 dpi
×
4 100 dpi
○
3 15.4 l/mm
×
2 - -
1 7.7 l/mm
×
0 3.85 l/mm
○
00100003 00100023 00100043 00100063 7-3 - - 00000001
2 (1200 dpi)
×
1 (800 dpi)
×
Y119930-3
