d-Color MF4003/MF3303
P THEORY OF OPERATION > 8. FK-517
P-86
8. FK-517
8.1COMMUNICATION CONTROL
8.1.1FIF bits of DIS, DTC and DCS
NOTE
▪ Considered to be A4 width when the DIS recording paper width is invalid (1, 1).
Becomes a FIF error when the DCS recording paper width is invalid (1, 1).
▪ Considered to be unlimited when the DIS recording paper length is invalid (1, 1).
Considered to be unlimited when the DCS recording paper length is invalid (1, 1).
The DCS recording paper length in a machine is made to be of the same length as that in a remote station and is sent.
▪ Considered to be 2400 bps when the DIS transmission speed is an undefined value.
Becomes a FIF error when the DCS transmission speed is an undefined value.
▪ Considered to be 40ms instruction when the MSLT of DCS is an undefined value.
▪ Considered to have mm ability when DIS inch ability and mm ability are both set to OFF.
Considered to be 200x100 pels/inch when the DCS resolution receives the inch instruction at 3.85 l/mm.
Becomes a FIF error when more than one of bit41, 42 and 43 are set to on in the resolution of DCS.
▪ Becomes a FIF error when DCS receives the MMR instruction without ECM.
▪ Becomes a FIF error when DCS receives the file transfer (BFT) instruction without ECM.
▪ Becomes a FIF error when DCS shows an instruction which exceeds the ability of the machine.
▪ FIF of DIS/DTC is not sent if last octet is 0.
DCS sends FIF whose length is the same as that of the machine.
▪ When undefined signals are received, they are received and ignored in consideration of the future expansion. (not an error)
(1)FIF data configuration list (DIS/DTC)
(a)Octet 4
bit Function Contents Default
1 T.37 Internet fax (Simple mode) 0
2 Reserved 0
3 T.38 real time Internet fax 0
4 Third generation mobile network 0
5 Reserved 0
6 V.8 ability 0
7 ECM frame 1: 64 octet
0: 256 octet
0
8 Reserved 0
(b)Octet 5
bit Function Contents Default
9 Ready for polled transmission 1: polled transmission documents exist
0: no polled transmission documents
@
10 Receiver ability 1: Reception is possible.
0: Reception is impossible.
@
11 Transmission speed ability Refer to *1. 1
12 1
13 0
14 1
15 R8×7.7 l/mm and/or 200×200 pels/25.4 mm 1
16 Two-dimensional coding ability 1: MR
0: MH
1
• @: Changes to 0 or 1 according to a status of devices.
• *1: Transmission speed ability (bit 11, 12, 13 and 14)
11 12 13 14 Contents Transmission speed
0 0 0 0 V27 ter fall back mode 24
0 1 0 0 V27 ter 48, 24
1 0 0 0 V29 96, 72
1 1 0 0 V27 ter & V29 96, 72, 48, 24
1 1 0 1 V27 ter & V29 & V17 144, 120, 96, 72, 48, 24
(c)Octet 6
bit Function Contents Default
17 Recording paper width ability bit 17, 18
0,0=A4
0,1=A3
1,0=B4
0
18 1
Service Manual
Y119930-3
