I SERVICE MODE > 16. FAX
I-87
Setting item Contents Setting
value
Default setting
Network Settings4 Network Settings5
Intermittent
Sound
○ (JP)
OFF
○ (US/EU)
• To make the following settings according to the setting value in Tone Det. Set.
When [Continuous Sound] is selected in Tone Det. Set.
Setting item Contents Setting range Default setting
Wait Time To set the dial tone waiting time. 1 to 10 s
(Step: 1 s)
3 s
Detection Time To set the dial tone detection time. 20 to 5000 ms
(Step: 20 ms)
1000 ms
Interr. Det. Time To set the interruption detection time. 0 to 1000 ms
(Step: 20 ms)
0 ms
Tone Det. Frequency (*) To set the dial tone detection frequency pattern. 1 to 23
(Step: 1)
8
When [Intermittent Sound] is selected in Tone Det. Set.
Setting item Contents Setting range Default setting
Minimum ON Time To set the minimum ON time. 20 to 5000 ms
(Step: 20 ms)
100 ms
Maximum ON Time To set the maximum ON time. 20 to 5000 ms
(Step: 20 ms)
1000 ms
Minimum OFF Time To set the minimum dial tone OFF time. 20 to 5000 ms
(Step: 20 ms)
100 ms
Maximum OFF Time To set the maximum dial tone OFF time. 20 to 5000 ms
(Step: 20 ms)
400 ms
Detection Count To set the number of times of tone detection. 1 to 10 count
(Step: 1 count)
3 count
Wait Time To set the dial tone waiting time. 1 to 10 s
(Step: 1 s)
3 s
Tone Det. Frequency (*) To set the dial tone detection frequency pattern. 1 to 23
(Step: 1)
8
When [OFF] is selected in Tone Det. Set.
Setting item Contents Setting range Default setting
Pre-PauseTime To set the pre-pause time. 1 to 10 s
(Step: 1 s)
3 s
Tone Det. Frequency (*) To set the dial tone detection frequency pattern. 1 to 23
(Step: 1)
8 (400±100Hz)
• *: The setting values of Tone Det. Frequency are shown as below.
*: Details of Tone Det. Frequency setting.
Setting
value
Contents Setting
value
Contents Setting
value
Contents
1 155±65Hz 9 425±100Hz 17 425±150Hz
2 1155±25Hz 10 440±100Hz 18 440±150Hz
3 375±75Hz 11 375±125Hz 19 465±205Hz
4 400±75Hz 12 400±125Hz 20 350±25Hz (Dual)
5 425±75Hz 13 425±125Hz 21 620±25Hz (Dual)
6 440±75Hz 14 440±125Hz 22 400±75Hz (Dual)
7 375±100Hz 15 375±150Hz 23 550±100Hz (Dual)
8 400±100Hz 16 400±150Hz - -
16.4System
NOTE
▪ This setting is displayed only for “Line1.”
Display Setting
Setting item Contents Setting value Default setting
Closed area Rx To set whether or not to use the menu display for closed reception function by
using F-code for junk fax messages.
ON
○
OFF
Re-Transmission To set whether or not to use the re-transmission function. ON
○
OFF
Y119930-3
