d-Color MF4003/MF3303
L TROUBLESHOOTING > 10. DIAGNOSTIC CODES
L-113
10. DIAGNOSTIC CODES
10.1Outline
• The diagnostic code is a 22-digit hexadecimal code indicating a communication conditions and status.
• The diagnostic code is printed on the activity report.
• The purpose of the diagnostic code is to obtain detailed information of communication results and conditions so as to analyze
communication troubles.
10.2Explanation
10.2.1The diagnostic code
XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15) (16) (17) (18) (19) (20) (21) (22)
10.2.2Information of communication results and conditions
Items Description
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
(1) Types of call out /
called
F network
(Japan)
PSTN Dial-in
(Japan)
Telephone Group One-touch
dialing
Abbreviated
dialing
Key pad
dialing
(2) Communication
mode
Sending Error page
resending
Forwarding
transmission
Polled
transmission
Receiving Recovery
transmission
Called
turnaround
Polling RX
(3) Applied function
specification
Mixed size
transmission
All pages/
cover
Frame
erasure
transmission
Book mode
transmission
2in1
transmission
Original size
appointing TX
Upside down Special
scanning non
standard/
Zfold/Long
(Not used)
(4) One-time
communication
parameter
specification
Timer TX (Not used) CSRC PC-Fax
transmission
(RX/V2)
V.34 appoint
transmission
F-code
transmission
ECM
specification
TX
International
mode
transmission
(5) Communication
type
Relay Confidential Manual
transmission
Bulletin Line used (line 1 to 4)
(6) H_RES
specification 1 (HR)
400 dpi 300 dpi 200 dpi (Not used) 16 pels/mm (Not used) 8 pels/mm (Not used)
(7) H_RES
specification 2 (HR)
(Not used) (Not used) (Not used) (Not used) (Not used) (Not used) (Not used) 600 dpi
(8) V_RES
specification 1
400 dpi 300 dpi 200 dpi 100 dpi 15.4 l/mm (Not used) 7.7 l/mm 3.85 l/mm
(9) V_RES
specification 2
(Not used) (Not used) (Not used) (Not used) (Not used) (Not used) (Not used) 600 dpi
(10) Coding
specification
(Not used) (Not used) (JPEG) (JBIG) MMR MR MH THRU
(11) Original length
specification
(Not used) (Not used) (Legal) (Letter) A3 B4 A4 (Not used)
(12) Original length
specification
(Not used) No limits (Legal) (Letter) (Not used) B4 A4 (Not used)
(13) Speed
specification 0
(Not used) (Not used) (Not used) V.29-96 V.29-72 (Not used) V.27-48 V.27-24
(14) Speed
specification 1
V.17-144 V.17-120 V.17-96 V.17-72 (V.33-144) (V.33-120) (V.33-96) (V.33-72)
(15) Speed
specification 2
V.34-192 V.34-168 V.34-144 V.34-120 V.34-96 V.34-72 V.34-48 V.34-24
(16) Speed
specification 3
(Not used) (Not used) V.34-336 V.34-312 V.34-288 V.34-264 V.34-240 V.34-216
(17) MSLT
specification
(Not used) (Not used) (Not used) (Not used) (Not used) MSLT of resolution shown as vertical RES
(18) Communication
parameter
specification
ECM frame
size 0: 256 /
1: 64
ECM DIAG (CSRC) (BFT) (BTM) PWD SEP SUB
(19) Remote station
coding specification
(Not used) (Not used) (JPEG) (JBIG) MMR MR MH THRU
(20) Remote station
length specification
(Not used) (Not used) (Legal) (Letter) A3 B4 A4 (Not used)
(21) Remote station
length specification
(Not used) No limits (Legal) (Letter) (Not used) B4 A4 (Not used)
(22) Remote station
communication
(Not used) ECM DIAG (CSRC) (BFT) (BTM) PWD SEP SUB
Y119930-3
