I SERVICE MODE > 16. FAX
I-104
Items Address Data Default
Bit Contents Setting Data
For transmission 00130076 7-3 - - 00000000
2 Restrict plural fax destination
0: OFF
1: ON
OFF
1 Destination check display function
0: OFF
1: ON
OFF
0 Screen display during transmission
0: OFF
1: ON
OFF
Lower limit setting of the signal
send-out level setting range
00130077 7-0 Lower limit setting of the signal send-out level setting
range (-dBm)
-15 dBm 00001111
Character-to-search default for
FAX main screen
00130078 7-0 00000000 00000000 00000000 00000001: [Favorite]
00000000 00000000 00000100 00000000: [ABC]
00000000 00000000 00001000 00000000: [DEF]
00000000 00000000 00010000 00000000: [GHI]
00000000 00000000 00100000 00000000: [JKL]
00000000 00000000 01000000 00000000: [MNO]
00000000 00000000 10000000 00000000: [PQRS]
00000000 00000001 00000000 00000000: [TUV]
00000000 00000010 00000000 00000000: [WXYZ]
00000000 00000100 00000000 00000000: [etc]
[Favorite] 00000001
00130079 00000000
0013007A 00000000
0013007B 00000000
Initial program display page 0013007D 7-0 00000001: 1 page to 00011011: 27 pages
00000000: Temporary distribution
1 page 00000001
Destination type display setting 00130080 7-0 0: Do not display
1: Display
Do not display 00000000
00130081 00000000
00130082 00000000
00130083 00000001
No. of destination display
characters setting
00130084 7-0 00001110: 14 characters
00011000: 24 characters
14 characters 00001110
Lower limit of receive time
interval setting
00980000 7-0 Lower limit of receive time interval setting (unit: sec.) 0 sec. 00000000
Upper limit of receive time
interval setting
00980001 7-0 Upper limit of receive time interval setting (unit: sec.) 45 sec. 00101101
16.12Function parameter list (for separate line)
16.12.1Function setting 1
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
Transmission ATT 000E0090 000E01A0 000E02B0 000E03C0 7-4 Tone signal/FSK
transmission ATT (-dBm)
0000: 0 dBm to 1111: -15
dBm
-10 dBm 10101010
3-0 High-speed signal
transmission ATT (-dBm)
0000: 0 dBm to 1111: -15
dBm
-10 dBm
CED transmission
ATT
000E0091 000E01A1 000E02B1 000E03C1 7-4 - - 00001010
3-0 CED/ANS transmission ATT
(-dBm)
0000: 0 dBm to 1111: -15
dBm
-10 dBm
CD/SED ON level 000E0092 000E01A2 000E02B2 000E03C2 7-2 - - 00000011
1-0 CD/SED ON level
00: -33 dBm
01: -38 dBm
10: -43 dBm
11: -48 dBm
-48 dBm
Cable equalizer 000E0093 000E01A3 000E02B3 000E03C3 7-6 - - 00000000
5-4 Cable EQL transmission
selection
00: OFF
01: Send only
10: Receive only
11: Send and receive
OFF
Service Manual
Y119930-3
