d-Color MF4003/MF3303
L TROUBLESHOOTING > 3. TROUBLE CODE
L-59
• CC171: Dynamic link error during starting (AP1)
• CC172: Dynamic link error during starting (AP2)
• CC173: Dynamic link error during starting (AP3)
• CC174: Dynamic link error during starting (AP4)
• CC180: Dynamic link error during starting (LDR)
• CC181: Dynamic link error during starting (IBR)
• CC182: Dynamic link error during starting (IID)
• CC183: Dynamic link error during starting (IPF)
• CC184: Dynamic link error during starting (IMY)
• CC185: Dynamic link error during starting (SPF)
• CC186: Dynamic link error during starting (OAP)
Rank C
Trouble detection condition A dynamic link error occurs in the program on the CPU board due to an insufficient memory space available, a
ROM fault, or other reason when the main power switch is turned ON.
Trouble isolation -
Relevant electrical parts • CPU board (CPUB)
• Base board (BASEB)
Procedure
1. If the trouble code "C-C180" has occurred, check to install the appropriate loadable device driver for an authentication unit which is installed
to the MFP.
When the appropriate loadable device driver is not installed, reinstall the appropriate loadable device driver.
2. Check CPUB for proper installation and correct as necessary.
3. Replace CPUB.
4. Replace BASEB.
5.
If the above actions do not solve the problem, contact OLI.
3.17.8CC190
Contents
Trouble type CC190: Outline font load error
Rank C
Trouble detection condition An error occurred while loading the outline font.
Trouble isolation -
Relevant electrical parts • Storage board (STRGB)
• CPU board (CPUB)
• Base board (BASEB)
Procedure
1. Check STRGB for proper installation and correct as necessary.
2. Check CPUB for proper installation and correct as necessary.
3. Select [Service Mode] -> [State Confirmation] -> [Memory/Storage Adjustment] -> [Format] and perform the function.
4. Replace STRGB.
5. Replace CPUB.
6. Replace BASEB.
3.17.9CC191
Contents
Trouble type CC191: Setting parameter load error (LDR)
Rank C
Trouble detection condition Upon startup, the processing of the loadable device driver setting data file failed.
• RAM disk file creation failed.
• Reading from the flash ROM failed.
• An error occurred in API of the authentication module.
Trouble isolation -
Relevant electrical parts • CPU board (CPUB)
• Base board (BASEB)
Procedure
1. Turn OFF the main power switch, wait for 10 sec., then turn the switch ON.
2. Check CPUB for proper installation and correct as necessary.
3. Reinstall the loadable device driver.
4. Rewrite the firmware.
5. Replace CPUB.
6. Replace BASEB.
3.17.10CC211
Contents
Trouble type CC211: Authentication device general error
Rank C
