d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-99
Items Address Data Default
Bit Contents Setting Data
Main body polling transmission
command wait timer
000E0056 7-0 Timer for waiting a transmission command (+FDT) from
the main body during turnaround of polling transmission
(unit: sec.)
(Translated to 8 sec. when the value is "00000000")
8 sec. 00001000
Guaranteed time to switch post
message command receive
modes
000E0057 7-0 Guaranteed time to switch post message command
receive modes (unit: 1-ms increments) (Translated to
50 ms when the value is "00000000")
50 ms 00000000
V.8 time out (transmission) 000E0059 7-0 V.8 sequence timeout time (transmission) 0 00000000
V.8 time out (reception) 000E005A 7-0 V.8 sequence timeout time (reception) 0 00000000
Delay timer between TCF and
CFR
000E005B 7-0 Delay timer between TCF and CFR (unit: 10 ms) 0 00000000
TCF instantaneous interruption
allowable time
000E005C 7-0 TCF instantaneous interruption allowable time
(Disconnection confirmation time) (unit: 10 ms)
0 00000000
V.21 time at high/low speed
judgment
000E005D 7-0 V.21 time judged at high/low speed judgment (unit: 10
ms)
(Translated to 500 ms when the value is “00000000”)
500 ms 00000000
V.21 CD OFF time at high/low
speed judgment
000E005E 7-0 CD OFF time after V.21 judgment at high/low speed
judgment (unit: 10 ms)
(Translated to 2000 ms when the value is “00000000”)
2000 ms 00000000
Image data signal CD OFF
judgment time
000E005F 7-0 Image data signal CD OFF judgment time (unit: 10 ms)
(Translated to 2000 ms when the value is “00000000”)
2000 ms 00000000
V.21 send time after V.21 RX 000E0060 7-0 V.21 send time after V.21 reception (unit: 1 ms)
(Translated to 75 ms when the value is “00000000”)
75 ms 00000000
1stDialTone detection method
during PBX calls
000E0061 7 Continuous tone judgment
0: Yes
1: No
Yes 00000000
6-4 - -
3-0 Instantaneous break detection time (unit: 20 ms)
(Translated to 80 ms when the value is “0000”)
80 ms
16.11.3Report setting
Items Address Data Default
Bit Contents Setting Data
TTI/RTI setting 00120000 7 - - 00000011
6 SW for prohibiting the printing of the TTI address
0: Printing of the address allowed
1: Printing of the address not allowed
Printing of the
address allowed
5-4 RTI addition
00: OFF
01: (OFF)
10: INSIDE
11: OUTSIDE
OFF
3 TTI denominator display
0: Total
1: Individual
Total
2 Inhibition of TTI setting menu INSIDE display
0: No
1: Yes
No
1-0 - -
Report setting 1 00120001 7 - - 01101100
6 Addition of image
0: No
1: Yes
Yes
5 Automatic output of reserved report
0: No
1: Yes
Yes
4-3 TX result report
00: Not output
01: Output only at errors
10: Always output
11: (Normal output)
Output only at errors
2 Automatic output of sequential communication report
0: No
1: Yes
Yes
1-0 - -
To Next Page
