d-Color MF4003/MF3303
L TROUBLESHOOTING > 3. TROUBLE CODE
L-74
4. Execute [Service Mode] -> [State Confirmation] -> [Memory/Storage Adjustment] -> [Memory Check] -> [Rough Check], and check that no
abnormalities. When "NG" is displayed, replace the appropriate memory or PWB.
• WORK0: CPU board (CPUB) LPDDR4 main memory ChA
• WORK1: CPU board (CPUB) LPDDR4 main memory ChB
5. Replace CPUB.
3.20.4CFD7# - CFDA#
Contents
Trouble type CFD7# - CFDA#: Abort code
Rank C
Trouble detection condition -
Trouble isolation -
Relevant electrical parts CPU board (CPUB)
Procedure
1. Turn OFF the main power switch and unplug the power cord. Connect the power cord after 15 sec. or more, and turn ON the main power
switch.
2. Check CPUB for proper installation and correct as necessary.
3. Rewrite the firmware.
4. Execute [Service Mode] -> [State Confirmation] -> [Memory/Storage Adjustment] -> [Memory Check] -> [Rough Check], and check that no
abnormalities. When "NG" is displayed, replace the appropriate memory or PWB.
• WORK0: CPU board (CPUB) LPDDR4 main memory ChA
• WORK1: CPU board (CPUB) LPDDR4 main memory ChB
5. Replace CPUB.
3.20.5CFE3# - CFE6#
Contents
Trouble type CFE3# - CFE6#: Abort code
Rank C
Trouble detection condition -
Trouble isolation -
Relevant electrical parts CPU board (CPUB)
Procedure
1. Turn OFF the main power switch and unplug the power cord. Connect the power cord after 15 sec. or more, and turn ON the main power
switch.
2. Check CPUB for proper installation and correct as necessary.
3. Rewrite the firmware.
4. Execute [Service Mode] -> [State Confirmation] -> [Memory/Storage Adjustment] -> [Memory Check] -> [Rough Check], and check that no
abnormalities. When "NG" is displayed, replace the appropriate memory or PWB.
• WORK0: CPU board (CPUB) LPDDR4 main memory ChA
• WORK1: CPU board (CPUB) LPDDR4 main memory ChB
5. Replace CPUB.
3.20.6CFEF# - CFF2#
Contents
Trouble type CFEF# - CFF2#: Abort code
Rank C
Trouble detection condition -
Trouble isolation -
Relevant electrical parts CPU board (CPUB)
Procedure
1. Turn OFF the main power switch and unplug the power cord. Connect the power cord after 15 sec. or more, and turn ON the main power
switch.
2. Check CPUB for proper installation and correct as necessary.
3. Rewrite the firmware.
4. Execute [Service Mode] -> [State Confirmation] -> [Memory/Storage Adjustment] -> [Memory Check] -> [Rough Check], and check that no
abnormalities. When "NG" is displayed, replace the appropriate memory or PWB.
• WORK0: CPU board (CPUB) LPDDR4 main memory ChA
• WORK1: CPU board (CPUB) LPDDR4 main memory ChB
5. Replace CPUB.
Service Manual
Y119930-3
