d-Color MF4003/MF3303
I SERVICE MODE > 11. Counter
I-60
Counter item Counting method
3rd Feed Count Number of sheets of paper fed from tray 3.
Manual Tray Feed Count Number of sheets of paper fed from the manual bypass tray.
1st Feed Retry Count Count the frequency of paper feed retry of tray 1.
2nd Feed Retry Count Count the frequency of paper feed retry of tray 2.
3rd Feed Retry Count Count the frequency of paper feed retry of tray 3.
Manual Tray Feed retry Count Count the frequency of paper feed retry of manual bypass tray.
ADF (Feed) Count number of sheets of original fed through the take-up section of the DF.
Scan Count (Original Glass) Count the frequency of scanning through the original glass.
Counter clear
• To clear the count of a counter, select the specific part and touch Clear.
• It is not possible to clear the count of the counters for the fusing unit, transfer belt unit, drum unit, developing unit, and TCR new article
detection.
New Release
• After replacing a fusing unit or transfer belt unit, perform New Release to clear its life counter.
<Procedure>
1. Touch [New Release].
2. Open the front door or the lower front door.
3. Select a unit where New Release is made.
4. Press the Start key and perform New Release.
New Release Disable mode
• To enable a unit that is used temporarily for troubleshooting to be used again as a new unit in another machine, the New Release Disable
mode is provided.
• Applicable units are the following units that have the new unit detection feature.
• Drum unit, developing unit
• See the “Notes when using the New Release Disable mode” for the method of enabling the New Release Disable mode.
11.3Service Call
• To count and display how many times trouble has been detected on a trouble type basis.
• Use this feature to check how many times trouble has occurred.
NOTE
▪ In the service call counter list, “Reboot” shows how many times abort code (C-FXXX) has occurred.
11.4Section Service Call
• To count and display how many times trouble has been detected during a certain period, i.e. an interval between service visits, on a trouble
type basis.
• Use this feature to check how many times trouble has occurred in a certain period, i.e. an interval between service visits.
• By clearing the counter at the time of visit to your customer, i.e. service visit, you can check how many times trouble has occurred since the
previous visit. To reset the counter, use [Counter Reset].
NOTE
▪ In the zone service call list, “Reboot” shows how many times abort code (C-FXXX) has occurred.
11.5Warning
• To count and display how many times malfunction code has been detected on a malfunction code type basis.
• To clear of count value.
• To check the number of warning conditions detected according to the warming type.
<Procedure>
1. To clear the count of a counter, select the specific part and touch Clear.
2. If a counter is cleared mistakenly, touch Interrupt which will undo the clearing operation.
11.6Maintenance
• To set a count value for maintenance of any given part.
• When any given part is replaced.
<Procedure (Maint.-Set)>
1. Enter the maintenance counter value from the 10-key pad.
<Procedure (Maint.-Count)>
1. The number of sheets that have been ejected is counted up. (1 sided: 1 count, 2 sided: 2 count)
2. Touch Clear will clear the count.
11.7Service Total
• Use to check the total number of printed pages including the ones printed by the Service Mode.
• Total number of printed pages: No. of pages printed by user mode and Service Mode.
• To display the count value for the service total counter.
• To display the count value for service total counter of each paper size.
Display item
Total Service Total, Service Total(Duplex)
Paper Size 1 A4, A5, A6, B5, B6, Postcard, 8
1
/
2
×14, 8
1
/
2
×11, 7
1
/
4
×10
1
/
2,
5
1
/
2
×8
1
/
2
, 4×6, Foolscap
Service Manual
Y119930-3
