d-Color MF4003/MF3303
L TROUBLESHOOTING > 1. JAM CODE
L-4
JAM type JAM detection timing Ref. page
Misfeed at tray 3 paper
feed section (When PF-P20
or PF-P21 is installed)
Paper jam of a sheet of paper left at the tray 3 paper feed section results, if
the tray 3 transport sensor (PS6/3) is turned ON (unblocked) when the main
power switch is turned ON, a door is opened and closed, or a misfeed or
malfunction is reset.
L.1.5.4 13-01, 13-40
Paper jam of a sheet of paper left at the tray 3 paper feed section results, if a
sheet of paper is determined to exist at a position detected when the main
power switch is turned ON, a door is opened and closed, or a misfeed or
malfunction is reset.
Misfeed at vertical transport
section (When PF-P20 or
PF-P21 is installed)
Paper jam of a sheet of paper left at the vertical transport section results, if a
sheet of paper is determined to exist at a position detected when the main
power switch is turned ON, a door is opened and closed, or a misfeed or
malfunction is reset.
L.1.6.1 20-02, 20-10, 20-11, 20-12,
20-21, 20-26
Misfeed at 2nd transfer
section
Paper jam of a sheet of paper left at the 2nd transfer section results, if the
registration sensor (PS9) is turned ON (blocked) when the main power switch
is turned ON, a door is opened and closed, or a misfeed or malfunction is
reset.
L.1.7.1 30-01, 30-03
Paper jam of a sheet of paper left at the 2nd transfer section results, if the
fusing loop sensor (PS10) is turned ON (blocked) when the main power switch
is turned ON, a door is opened and closed, or a misfeed or malfunction is
reset.
Paper jam of a sheet of paper left at the 2nd transfer section results, if a sheet
of paper is determined to exist at a position detected when the main power
switch is turned ON, a door is opened and closed, or a misfeed or malfunction
is reset.
Misfeed at paper exit
section
Paper jam of a sheet of paper left at the paper exit section results, if the paper
exit sensor (PS13) is turned ON (unblocked) when the main power switch is
turned ON, a door is opened and closed, or a misfeed or malfunction is reset.
L.1.7.2 32-05, 32-06, 32-31
Paper jam of a sheet of paper left at the paper exit section results, if a sheet of
paper is determined to exist at a position detected when the main power
switch is turned ON, a door is opened and closed, or a misfeed or malfunction
is reset.
Misfeed at DF document
feed section
Paper jam of a sheet of paper left at the DF document feed section results, if
the after separate sensor (PS16) is turned ON when the main power switch is
turned ON, a door is opened and closed, or a misfeed or malfunction is reset.
L.1.8.1 66-02
Misfeed at DF document
transport section
Paper jam of a sheet of paper left at the DF document transport section
results, if the document registration sensor (PS17) is turned ON (unblocked)
when the main power switch is turned ON, a door is opened and closed, or a
misfeed or malfunction is reset.
L.1.8.2 66-13, 66-33
Misfeed at DF document
reading section
Paper jam of a sheet of paper left at the DF document reading results, if the
document before read sensor (PS18) is turned ON when the main power
switch is turned ON, a door is opened and closed, or a misfeed or malfunction
is reset.
L.1.8.3 66-05
Misfeed at duplex pre-
registration section
Paper jam of a sheet of paper left at the duplex pre-registration section
results, if a sheet of paper is determined to exist at a position detected when
the main power switch is turned ON, a door is opened and closed, or a
misfeed or malfunction is reset.
L.1.9.1 92-01, 92-02, 92-03, 92-04
Misfeed at duplex transport
section
Paper jam of a sheet of paper left at the duplex transport section results, if the
ADU transport sensor (PS11) is turned ON (unblocked) when the main power
switch is turned ON, a door is opened and closed, or a misfeed or malfunction
is reset.
L.1.9.2 93-03
Paper jam of a sheet of paper left at the duplex transport section results, if a
sheet of paper is determined to exist at a position detected when the main
power switch is turned ON, a door is opened and closed, or a misfeed or
malfunction is reset.
1.51#-##
1.5.110-01, 10-02, 10-40
Contents
JAM type Misfeed at manual bypass paper feed section
JAM code 10-01, 10-02, 10-40
JAM detection timing 10-01 The leading edge of the paper is not turned ON (blocked) the registration sensor (PS9) even after
the lapse of a given period of time after the manual bypass tray starts to feed paper.
10-02 For paper fed from the manual bypass tray, loop forming has not been complete before a sheet
enters the registration roller because the rise timing of load to perform registration is earlier than the
rise timing of load to form a loop.
10-40 For paper fed from the manual bypass tray, the image write start signal permit continues to be
disabled for a predetermined period of time after the timing of the image write start signal output.
To Next Page
