Olivetti d-Color MF4003 User Manual

d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-117
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
2 Training data fix operation
mode
0: During V.17 RX
1: During V.17/V.27ter/V.29
RX
During V.17 RX
1 EQFZ operation
0: Yes
1: No
Yes
0 EQFZ operation mode
0: During V.17 RX
1: During V.17/V.27ter/V.29
RX
During V.17 RX
FED OFF waiting
time during V.21
set-up
000E0130 000E0240 000E0350 000E0460 7-0 FED OFF waiting time during
V.21 set-up (unit: 5 ms)
(Translated to 400 ms when
the value is “00000000”)
400 ms 00000000
Operation at V.17
RX error
000E0134 000E0244 000E0354 000E0464 7-2 R06 error detection
×
00000000
1 V.29 communication at V.17
RX error
0: No
1: Yes
Yes
0 Condition for V.29
communication at V.17 RX
error
0: For R06 error (equivalent)
only
1: For all RX errors
For R06 error
(equivalent) only
V.29
communication
time at V.17 RX
error
000E0135 000E0245 000E0355 000E0465 7-0 Time limited for V.29
communication from V.17
error occurrence (unit: min.)
0 min. 00000000
16.12.6Fax capacity setting
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
Reception main
scan line resolution
ability
000F0000 000F0020 000F0040 000F0060 7 400 dpi
○
10101010
6 300 dpi
×
5 200 dpi
○
4 - -
3 16 pels/mm
○
2 - -
1 8 pels/mm
○
0 - -
000F0001 000F0021 000F0041 000F0061 7-3 - - 00000001
2 (1200 dpi)
×
1 (800 dpi)
×
0 600 dpi
○
Reception sub
scanning resolution
ability
000F0002 000F0022 000F0042 000F0062 7 400 dpi
○
10111011
6 300 dpi
×
5 200 dpi
○
4 100 dpi
○
3 15.4 l/mm
○
2 - -
1 7.7 l/mm
○
0 3.85 l/mm
○
000F0003 000F0023 000F0043 000F0063 7-3 - - 00000001
2 (1200 dpi)
×
1 (800 dpi)
×
0 600 dpi
○
Y119930-3
Service Manual
