M PARTS/CONNECTOR LAYOUT DRAWING > 2. CONNECTOR LAYOUT
DRAWING
M-13
d-Color MF4003/MF3303
2.1.3 EK-P08
USB hub board (USBHB)
PJ05 (2pin)
PJ10 (4pin)
PJ14 (4pin)
PJ1
1 (8pin)
PJ06 (5pin)
2.1.4EK-P09
USB hub board (USBHB)
PJ9 (10pin)
PJ05 (2pin)
PJ10 (4pin)
PJ14 (4pin)
PJ11 (8pin)
PJ06 (5pin)
2.1.5UK-P19
Multi feed detection board/TX (MFDB/TX)
CN111(3pin)
Multi feed detection board/RX (MFDB/RX)
CN110
(4pin)
Y119930-3
Service Manual
