d-Color MF4003/MF3303
L TROUBLESHOOTING > 17. IC PROTECTOR
L-154
17. IC PROTECTOR
17.1Outline
• To increase product safety, this MFP has an IC protector installed in each board. ICP is a component that protects IC.
• If the amount of the current supplied to the electrical parts such as motor exceeds the set level, ICP trips to protect IC from over current.
• The IC is provided with an over current protective function which works when the current exceeds the specified value to protect the IC from
over current.
For an IC that is provided with an over current protective function and being protected, if the problem is solved, the MFP will recover after
turning OFF/ON the main power switch without replacing the board.
• The following list contains IC protector installed in each board, related devices, and symptoms when an over current occurs.
17.2IC protector list
17.2.1d-Color MF4003/MF3303
(1)Base board
(a)ICP
ICP No. Symbol Target part name When ICP trips
Symptom in each load Trouble code and
others
F1E FSDB FS drive board No operation -
F2E FM1 Machine cooling fan Power line A19 error C7613
FM2 Toner suction fan
F3E M7 Polygon motor Power line A20 error C7615
F4E CL1 1st transfer pressure clutch Power line A7 error C7607
CL2 Bypass tray paper feed clutch
CL3 Tray 1 paper feed clutch
CL4 Registration clutch
CL5 ADU transport clutch
CL6 ADU forward rotation clutch
CL7 ADU reverse rotation clutch
SD1 Exit path switch solenoid
F5E M4 Toner supply motor/YM Power supply malfunction C5701
M5 Toner supply motor/CK
F6E HVPS High voltage unit Power line A5 error C7605
F8E PCCB PC control board Power line A10 error C760A
F10E PS1 Front door sensor Front door open display -
- Scanner unit Drive system home sensor malfunction C6102
- DF
F11E M6 Tray 1 lift-up motor Tray 1 feeder up/down abnormality C0202
CUDB Clean unit drive board Power line A15 error C760F
F15E - 3.3 V DC/DC converter in mechanical
controller of base board
Mechanical controller ASIC communication
error
C40A6
F16E - Scanner unit Drive system home sensor malfunction C6102
- DF
F18E M1 Main motor Main motor failure to turn C5102
F19E M3 Fusing motor Fusing motor failure to turn C3201
F20E M2 Color motor Color motor failure to turn C2253
PTC1E TBSB/Y Toner cartridge set board/Y Toner Cartridge Installation Error -
TBSB/M Toner cartridge set board/M -
TBSB/C Toner cartridge set board/C -
TBSB/K Toner cartridge set board/K -
TCRS/Y TCR sensor/Y Imaging Unit Installation Error -
TCRS/M TCR sensor/M -
TCRS/C TCR sensor/C -
TCRS/K TCR sensor/K -
PTC2E - 3.3 V DC/DC converter in mechanical
controller of base board
Mechanical controller ASIC communication
error
C40A6
ICP1 FM3 CPU cooling fan MFP control board CPU temperature failure C5372
To Next Page
