L TROUBLESHOOTING > 4. TROUBLESHOOTING USING SELF-DIAG. (FULL)
L-76
d-Color MF4003/MF3303
4.3Error Code List
Error code Target device Diagnosis item Reason of error Relevant electrical parts
E1-1 NVMeSSD Device recognition Engagement failure
Mounting failure
Storage board (STRGB)
CPU board (CPUB)
E1-2 R/W check STRGB error (data failure) Storage board (STRGB)
E1-3 S.M.A.R.T diag. STRGB error (data failure) Storage board (STRGB)
E1-4 MFP FW checksum STRGB error (data failure) MFP firmware
E1-5 Partition check STRGB error (data failure) Storage board (STRGB)
E3-1 I2C TPM Connection failure
Parts defect
TPM board (TPMB)
CPU board (CPUB)
Base board (BASEB)
E3-2 AUDIO (control) Connection failure
Parts defect
CPU board (CPUB)
Base board (BASEB)
E3-3 PS-CPU Connection failure
Parts defect
CPU board (CPUB)
Base board (BASEB)
E4-1 System/image
memory
WORK0 (Main memory ch.A) Engagement failure
Mounting failure
DRAM failure
CPU board (CPUB)
E4-2 WORK1 (Main memory ch.B) Engagement failure
Mounting failure
DRAM failure
CPU board (CPUB)
E5-1 Various USB
devices
IRIS0 Connection failure
Parts defect
CPU board (CPUB)
E5-2 USB3.0-HUB chip (base board) Connection failure
Parts defect
CPU board (CPUB)
Base board (BASEB)
E5-3 USB2.0-HUB chip (base board) Connection failure
Parts defect
Base board (BASEB)
E5-4 USB device HUB chip (USB hub
board)
Connection failure
Parts defect
USB hub board (USBHB)
Base board (BASEB)
E5-5 DAC-IC Connection failure
Parts defect
USB hub board (USBHB)
E5-7 FAX board (line 1) Connection failure
Parts defect
FAX board (FAXB)
Base board (BASEB)
E5-11 Upgrade kit (UK-221) Connection failure
Parts defect
Wireless LAN board (WLANB)
Base board (BASEB)
E5-12 Authentication unit Connection failure
Parts defect
Authentication unit
Base board (BASEB)
E6-1 CIS module I/P image bus check (front side) Image bus failure CIS cable
CIS module (IR CIS)
CPU board (CPUB)
Base board (BASEB)
E6-2 Line RAM comparison (front side) CIS sensor failure CIS module (IR CIS)
E7-1 DF CIS module I/P image bus check (back side) Image bus failure CIS cable
DF CIS module (DF CIS)
CPU board (CPUB)
Base board (BASEB)
E7-2 Line RAM comparison (back side) CIS sensor failure DF CIS module (DF CIS)
E8-1 DF control board MINET communication check ADF microcomputer
communication failure
Connection cable
DF control board (DFCB)
CPU board (CPUB)
Base board (BASEB)
E11-1 CPU board Compress/exp check S800 error CPU board (CPUB)
E11-2 O/P image bus check S800 error CPU board (CPUB)
E12-1 PCIe PCIe device check IRIS(0) PCIe device error CPU board (CPUB)
E12-2 PCIe device check IRIS(1) CPU board (CPUB)
E12-3 PCIe device check NVMeSSD Storage board (STRGB)
CPU board (CPUB)
Troubleshooting against multiple error codes
Error code Action
E1-1, E5-1, E12-1, E12-3 Execute E12-1.
E4-1, E4-2, E11-1, E11-2 Execute E4-1.
Service Manual
Y119930-3
