L TROUBLESHOOTING > 3. TROUBLE CODE

L-24

d-Color MF4003/MF3303

3.6List of the trouble code

Trouble Code Contents Rank Self-diag. (Full)

C0103 Tray 2 drive motor malfunction (When PF-P20 or PF-P21 is installed) B -

C0104

Tray 3 drive motor malfunction (When PF-P20 or PF-P21 is

installed) (d-Color MF4003 only)

B -

C0202 Tray 1 feeder up/down abnormality B -

C0204 Tray 2 feeder up/down abnormality (When PF-P20 or PF-P21 is installed) B -

C0206

Tray 3 feeder up/down abnormality (When PF-P20 or PF-P21 is

installed) (d-Color MF4003 only)

B -

C2153 Transfer belt spacing fault at K pressure switching B -

C2154 Transfer belt contact fault at all pressure switching B -

C2155 Transfer belt contact fault after K pressure established B -

C2156 Transfer belt spacing fault after all pressure established B -

C2253 Color motor failure to turn B -

C2254 Color motor turning at abnormal timing B -

C2350 Toner suction fan failure to turn B -

C2411 Imaging unit/C new article release B -

C2412 Imaging unit/M new article release B -

C2413 Imaging unit/Y new article release B -

C2414 Imaging unit/K new article release B -

C2551 Abnormally low toner density detected cyan TCR sensor B -

C2552 Abnormally high toner density detected cyan TCR sensor B -

C2553 Abnormally low toner density detected magenta TCR sensor B -

C2554 Abnormally high toner density detected magenta TCR sensor B -

C2555 Abnormally low toner density detected yellow TCR sensor B -

C2556 Abnormally high toner density detected yellow TCR sensor B -

C2557 Abnormally low toner density detected black TCR sensor B -

C2558 Abnormally high toner density detected black TCR sensor B -

C2559 Cyan TCR sensor adjustment failure B -

C255A Magenta TCR sensor adjustment failure B -

C255B Yellow TCR sensor adjustment failure B -

C255C Black TCR sensor adjustment failure B -

C2561 Cyan TCR sensor failure B -

C2562 Magenta TCR sensor failure B -

C2563 Yellow TCR sensor failure B -

C2564 Black TCR sensor failure B -

C2650 Main backup media access error C -

C2A21 Toner cartridge/C new release failure C -

C2A22 Toner cartridge/M new release failure C -

C2A23 Toner cartridge/Y new release failure C -

C2A24 Toner cartridge/K new release failure C -

C3201 Fusing motor failure to turn B -

C3202 Fusing motor turning at abnormal timing B -

C3425 Fusing warm-up trouble A -

C3722 Fusing abnormally high temperature detection (Edge of the heating roller) A -

C3725 Fusing abnormally high temperature detection (Main of the heating roller) A -

C3726 Fusing abnormally high temperature detection (Center of the heating

roller)

A -

C3731 Fusing abnormally high temperature detection (hard protector) A -

C3825 Fusing abnormally low temperature detection (Main of the heating roller) A -

C3826 Fusing abnormally low temperature detection (Center of the heating roller) A -

C3922 Fusing sensor wire breaks detection (Edge of the heating roller) A -

C3925 Fusing sensor wire breaks detection (Main of the heating roller) A -

C3926 Fusing sensor wire breaks detection (Center of the heating roller) A -

C392B Fusing sensor wire breaks detection (difference of temperature) A -

C4091 Engine communication error C -

C40A2 Mechanical controller PF communication data error C -

C40A3 Mechanical controller PF transmission timeout C -

Service Manual

Y119930-3
