d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-109
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
Busy tone OFF
time min. value
000E00C4 000E01D4 000E02E4 000E03F4 7-0 Busy tone OFF time min.
value (unit: 20 ms)
400 ms (JP/US)
180 ms (EU)
0x14 (JP/
US)
0x09 (EU)
*1: PBX dial tone detection frequency pattern
Data Contents
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 1 155±65Hz
0 0 0 1 0 1155±25Hz
0 0 0 1 1 375±75Hz
0 0 1 0 0 400±75Hz
0 0 1 0 1 425±75Hz
0 0 1 1 0 440±75Hz
0 0 1 1 1 375±100Hz
0 1 0 0 0 400±100Hz
0 1 0 0 1 425±100Hz
0 1 0 1 0 440±100Hz
0 1 0 1 1 375±125Hz
0 1 1 0 0 400±125Hz
0 1 1 0 1 425±125Hz
0 1 1 1 0 440±125Hz
0 1 1 1 1 375±150Hz
1 0 0 0 0 400±150Hz
1 0 0 0 1 425±150Hz
1 0 0 1 0 440±150Hz
1 0 0 1 1 465±205Hz
1 0 1 0 0 350±25Hz (Dual)
1 0 1 0 1 620±25Hz (Dual)
1 0 1 1 0 400±75Hz (Dual)
1 0 1 1 1 550±100Hz (Dual)
16.12.3Function setting 3
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
Ringer detection
pattern
000E00C5 000E01D5 000E02E5 000E03F5 7 Custom mode
0: OFF (in accordance with
bits 3-0)
1: ON (in accordance with
bits 5-4)
OFF (in accordance
with bits 3-0)
00000000
6 - -
5-4 Custom mode ringer
detection pattern
00: Single
01: Double
10: Triple
* The standard time is
configured with
DRPD_Custom[].
Configure commonly with
DRPD_1st[] through 3rd[] to
adjust the detection time.
Single
3-0 Ringer detection pattern
0000: Nomal
0001: DRPD_Single
0010: DRPD_Double
0011: DRPD_Triple1
0100: DRPD_Triple2
0101: DRPD_NZDA1
0110: DRPD_NZDA2
0111: DRPD_NZDA3
1000: DRPD_NZDA4
1001: DRPD_Duet
Nomal
Y119930-3
