d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-108
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
1st dial tone
waiting time
000E00B6 000E01C6 000E02D6 000E03E6 7-0 1st dial tone waiting time or
pre-pause time (unit: 1 sec.)
3 sec. (JP/US)
4 sec. (EU)
00000011
(JP/US)
00000100
(EU)
1st dial tone
instantaneous
break detection
time
000E00B7 000E01C7 000E02D7 000E03E7 7-0 Instantaneous shutdown
detection time (unit: 20 ms) or
tone detection no. of times
(unit: No. of times)
0 ms (JP/US)
100 ms (EU)
00000000
(JP/US)
00000101
(EU)
2nd dial tone
detection pattern
000E00B8 000E01C8 000E02D8 000E03E8 7 - - 00001000
(JP)
01010100
(US)
00010011
(EU)
6 Tone type
0: Single
1: Dual
Single (JP/EU)
Dual (US)
5 - -
4-0 PBX dial tone detection
frequency pattern reference
(*1)
400 ±100 Hz (JP)
350 ±25 Hz (Dual)
(US)
465 ±205 Hz (EU)
2nd dial tone
detection time
000E00B9 000E01C9 000E02D9 000E03E9 7-0 2nd dial tone detection time
or ON time max. value (unit:
20 ms)
160 ms (JP)
1000 ms (US)
520 ms (EU)
00001000
(JP)
00110010
(US)
00011010
(EU)
2nd dial tone ON
time min. value
000E00BA 000E01CA 000E02DA 000E03EA 7-0 2nd dial tone ON time min.
value (unit: 20 ms)
40 ms (JP)
0 ms (US/EU)
00000010
(JP)
00000000
(US/EU)
2nd dial tone OFF
time max. value
000E00BB 000E01CB 000E02DB 000E03EB 7-0 2nd dial tone OFF time max.
value (unit: 20 ms)
200 ms (JP)
0 ms (US/EU)
00001010
(JP)
00000000
(US/EU)
2nd dial tone OFF
time min. value
000E00BC 000E01CC 000E02DC 000E03EC 7-0 2nd dial tone OFF time min.
value (unit: 20 ms)
80 ms (JP)
0 ms (US/EU)
00000100
(JP)
00000000
(US/EU)
2nd dial tone
waiting time
000E00BD 000E01CD 000E02DD 000E03ED 7-0 2nd dial tone waiting time or
pre-pause time (unit: 1 sec.)
3 sec. 00000011
2nd dial tone
instantaneous
break detection
time
000E00BE 000E01CE 000E02DE 000E03EE 7-0 Instantaneous shutdown
detection time (unit: 20 ms) or
tone detection no. of times
(unit: No. of times)
60 ms (JP)
0 ms (US/EU)
00000011
(JP)
00000000
(US/EU)
3rd dial tone
detection pattern
000E00BF 000E01CF 000E02DF 000E03EF 7 - - 00001000
(JP)
01010100
(US)
00010011
(EU)
6 Tone type
0: Single
1: Dual
Single (JP/EU)
Dual (US)
5 - -
4-0 PBX dial tone detection
frequency pattern reference
(*1)
400 ±100 Hz (JP)
350 ±25 Hz (Dual)
(US)
465 ±205 Hz (EU)
Busy dial tone
detection pattern
000E00C0 000E01D0 000E02E0 000E03F0 7 - 400 ±100 Hz (JP)
620 ±25 Hz (Dual)
(US)
425 ±100Hz (EU)
00001000
(JP)
01010101
(US)
00001001
(EU)
6 Tone type
0: Single
1: Dual
5 -
4-0 PBX dial tone detection
frequency pattern reference
(*1)
Busy tone ON time
max. value
000E00C1 000E01D1 000E02E1 000E03F1 7-0 Busy tone ON time max.
value (unit: 20 ms)
600 ms (JP/US)
540 ms (EU)
0x1e (JP/
US)
0x1b (EU)
Busy tone ON time
min. value
000E00C2 000E01D2 000E02E2 000E03F2 7-0 Busy tone ON time min. value
(unit: 20 ms)
400 ms (JP/US)
100 ms (EU)
0x14 (JP/
US)
0x05 (EU)
Busy tone OFF
time max. value
000E00C3 000E01D3 000E02E3 000E03F3 7-0 Busy tone OFF time max.
value (unit: 20 ms)
600 ms (JP/US)
620 ms (EU)
0x1e (JP/
US)
0x1f (EU)
Service Manual
Y119930-3
