d-Color MF4003/MF3303
P THEORY OF OPERATION
>
1.
d-Color MF4003/MF3303
P-19
[1]
[2]
[1]
Photoconductor
[2]
Electrostatic charger application terminal
1.6.3Imaging unit (photoconductor)
(1)Configuration
[3]
[4]
[5]
[6]
[2]
[1]
[1]
Transfer belt
[2]
Photoconductor
[3]
Toner collecting screw
[4]
Cleaning blade
[5]
Charging roller
[6]
Developing section
(2)Drive
[1]
[2]
[3]
[4]
[5]
[6]
Y119930-3
Service Manual
592
594
