I SERVICE MODE > 16. FAX
I-95
Items Address Data Default
Bit Contents Setting Data
0 Call acceptance rejected - Number display
0: Disconnected line
1: No response
Disconnection line
Recording paper priority
selection
000B0069 7-2 - - 00000000
1-0 00: Automatic selection
01: Fixed size
10: Priority
Automatic selection
Box number error operation 000B006A 7-5 - - 00000000
4 Print or not print the images received when the TSI
transfer terminates normally.
0: OFF
1: ON
ON
3 Operation with no routing registration or no registered
BOX upon the TSI routing turned ON
0: Print output
1: Saved in forced memory reception BOX
Print output
2-1 Reception of unregistered box sub No.
00: Print
01: Communication error
10: Auto create
Print
0 - -
16.11.2Function setting
Items Address Data Default
Bit Contents Setting Data
Error line processing/judgment 000E0000 7 RTP transmission
× (JP/US)
○ (EU)
00000001
(JP/US)
10000010
(EU)
6 - -
5 Error line recirculation
×
4 Addition of error sign
×
3 - -
2 Judgment of No. of sequential error lines
×
1 Error line rate judgment
× (JP/US)
○ (EU)
0 Judgment of No. of error lines
○ (JP/US)
× (EU)
No. of error lines-very good 000E0001 7-0 No. of lines-very good
No. of error lines≦VeryGoodErrorNum, MCF is
transmitted.
16 00010000
No. of error lines-good 000E0002 7-0 No. of error lines-good
VeryGoodErrorNum<No. of error lines≦GoodErrorNum,
RTP is transmitted
64 (JP/US)
128 (EU)
01000000
(JP/US)
10000000
(EU)
No. of error lines-bad 000E0003 7-0 No. of error lines-bad
GoodErrorNum<No. of error lines≦BadErrorNum, RTN
is transmitted.
No. of error lines>BadErrorNum, it is considered to be
error line over.
128 (JP/US)
255 (EU)
10000000
(JP/US)
11111111
(EU)
Rate of error lines-very good 000E0004 7-0 Rate of error lines-very good (%)
Rate of error lines≦VeryGoodErrorPercent, MCF is
transmitted.
5% 00000101
Rate of error lines-good 000E0005 7-0 Rate of error lines-good (%)
VeryGoodErrorPercent<Rate of error
lines≦GoodErrorPercent, RTP is transmitted.
Rate of error lines>GoodErrorPercent, RTN is
transmitted.
10% 00001010
No. of continuous error lines-
bad
000E0006 7-0 No. of bad judgment sequential error lines (Normal)
No. of sequential error lines≦ErrorContNormal, MCF is
transmitted.
No. of sequential error lines>ErrorContNormal, RTN is
transmitted.
3 00000011
No. of continuous error lines-
bad
000E0007 7-0 No. of bad judgment sequential error lines (Fine)
No. of sequential error lines≦ErrorContNormal, MCF is
transmitted.
6 00000110
