Olivetti d-Color MF4003 User Manual

d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-96
Items Address Data Default
Bit Contents Setting Data
No. of sequential error lines>ErrorContNormal, RTN is
transmitted.
No. of continuous error lines-
bad
000E0008 7-0 No. of bad judgment sequential error lines (300 dpi)
No. of sequential error lines≦ErrorContNormal, MCF is
transmitted.
No. of sequential error lines>ErrorContNormal, RTN is
transmitted.
9 00001001
No. of continuous error lines-
bad
000E0009 7-0 No. of bad judgment sequential error lines (Super fine)
No. of sequential error lines≦ErrorContNormal, MCF is
transmitted.
No. of sequential error lines>ErrorContNormal, RTN is
transmitted.
12 00001100
EP tone addition 000E000A 7-3 - - 00000110
2 V.17
○
1 - -
0 V.29
×
CED detection transmission
frequency
000E000B 7-2 - - 00000000
1 CED detection
0: Detect
1: Not detect
Detect
0 CED transmission frequency
0: 2100 Hz
2100 Hz
TSI/CSI/CIG parameter 000E000C 7 TSI transmission
0: No
1: Always
Always 11100000
6 CSI transmission
0: No
1: Always
Always
5 CIG transmission
0: No
1: Always
Always
4-1 - -
0 Character ID is put on CSI. 0
G3 mode error 000E000D 7 Ph-C8 min. limit timer at Non-ECM
0: No
1: Yes
No 00000000
(JP/US)
01000100
(EU)
6 Selection of “-” at dial top
0: OFF
1: ON
OFF (JP/US)
ON (EU)
5 RTN reception
0: step down
1: Line disconnect
step down
4 Remote reception ID received
0: After Ring detection only
1: No limit
After Ring detection
only
3 DIS retransmission interval in manual reception
0: 4.5 sec.
1: 3.0 sec.
4.5 sec.
2 DCN transmission at T200 0 (JP/US)
1 (EU)
1 DIS length at reception limited to 4byte
0: No limit
1: Limit
No limit
0 DCN transmitted at stop of ph.C 0
Step up/down 000E000E 7 Strict TCF check
0: Normal
1: Strict check
Normal 00000000
6-1 - -
0 The PC/BC of the PostMsg is checked while in the
ECM reception.
0: Yes
1: No
Yes
Delay timer between DCS-TCF 000E000F 7-0 DCS - TCF delay timer (unit: 10 ms) 80 ms 00001000
Delay timer between PIX-PMC 000E0010 7-0 PIX - PMC delay timer (unit: 10 ms) 80 ms 00001000
