Olivetti d-Color MF4003 User Manual

d-Color MF4003/MF3303
P THEORY OF OPERATION > 8. FK-517
P-107
(b)Protocol sequence example
Call
(NSF)/(CSI)/DIS
SID/SUB/(TSI)/DCS
TCF
CFR
PIX
EOM
MCF
(NSF)/(CSI)/DIS
(TSI)/DCS
TCF
CFR
PIX
EOP
MCF
DCN
Calling Called
8.2.3Transmission function
(1)Original scan mode
• The original scan mode is roughly classified by the regular original scan and the irregular original scan.
Regular original Irregular original Mode selection
Normal mode Irregular mode Default setting
Mixed original mode Scan setting
(a)Scan mode default setting
• The scan mode can be set by [Service Mode] -> [FAX] -> [System] -> [Scan Setting]. The default is the irregular mode.
Paper size detection Default Frame erasure
Irregular mode Trailing edge detection
○
Trailing edge erasure may not be
done.
Normal mode DF paper size sensor Automatically selected when using the page
related application function (book transmission,
etc.).
Frame erasure of all sides
8.2.4Reception function
(1)Reduction / division of reception
• Parameters related to reduction / division are set on the [Administrator Settings] -> [Fax Settings] -> [TX/RX Settings]. There are two
parameters as follows:
• [Min. Reduction for RX Print]: 96, 95, 94, ..., 87: a
• [Print Separate Fax Pages]: ON, OFF: b
• The reception recording mode is determined by the above-mentioned parameters, a and b.
(a)Auto reduction reception mode
• a = Don’t care (except 100)
• b = OFF
• The received documents are automatically reduced in the range of 35 to 96 %.
(b)Page division recording reception mode
• a = 96, 95, ..., 87
• b = ON
• Documents are reduced to three reduction rate (90 %, 86 %, or 82 %) determined by the width of received documents and the selected
recording paper. When they are still larger than a paper size, they are reduced to a value in “a” for the division recording.
• 90% = Fixed value
• 86%, 82% = Reduction rate determined by the main scanning direction
• The paper selection and division are determined in accordance with the following figure.
(c)Paper selected for division printing, magnification
A4S width at reception
Original
length=Receive
d original
size*(1/a)
Optimum
paper
Selected paper size / Division operation
Priority 1 Priority 2 Priority 3 Priority 4 Priority 5 Priority 6 Priority 7 Priority 8
152 mm or less A5 A5/a % A5S/69 % A4S/a % A4/a % B5S/84 % B5/a % B4/a % A3/a %
153 to 311 mm A4S A4S/a % A4/a % B4/a % A3/a % - - - -
Y119930-3
Service Manual
