d-Color MF4003/MF3303
I SERVICE MODE > 11. Counter
I-59
11. Counter
11.1Outline
• The counter displays the counts of various counters to allow the technical representative to check or set as necessary.
<Common procedure>
1. Call the Service Mode to the screen.
2. Touch [Counter] to show the counter menu.
3. Select the specific counter to be displayed.
4. To clear the counts of two or more counters within a group or across different groups at once, touch [Counter Reset], select the specific
counters to be cleared, and touch [END]. Two or more counters can be selected. (However, the [service call], [Service Total], [Jam], and
[Detail code history] counters cannot be selected.)
11.2Life
• To check the number of hours or times each of the different maintenance parts has been used.
• To clear the count of each counter.
• To perform New Release in fusing unit and transfer belt unit.
• To check how many times maintenance parts have been used.
• When each of the maintenance parts is replaced.
<Count method of each life counter>
Counter item Counting method
Fusing unit press times (Total) Counts the number of press time.
Fusing unit drive time (Press) Counts the total driving distance when pressuring.
Fusing unit drive mileage (Light press) Counts the total driving distance when lightly pressuring.
Fusing unit drive time (Press) Counts the total driving time when pressuring.
Fusing unit drive time (Light press) Count the total driving time when lightly pressuring.
Fusing unit edge predetermined tmp.
accumul. time(In printing)
Counts the total printing time when the fusing unit edge reaches the predetermined temperature.
Fusing unit edge predetermined tmp.
accumul. time(In standby)
Counts the total stand-by time when the fusing unit edge reaches the predetermined temperature.
Fusing unit center predetermined tmp.
accumul. time(In printing)
Counts the total printing time when the fusing unit center reaches the predetermined temperature.
Fusing unit center predetermined tmp.
accumul. time(In standby)
Counts the total stand-by time when the fusing unit center reaches the predetermined temperature.
Fusing unit CD width of max. mileage Counts the total paper feeding distance by each paper width, and shows paper width with the
longest total paper feeding distance.
Fusing unit max. mileage from each CD
width.
Counts the total paper feeding distance by each paper width, and shows the longest total paper
feeding distance.
Fusing Unit Rotation Time Counts how many hours the Fusing unit has turned.
Fusing Unit Page Count Counts how many sheets have been ejected. The counter of paper length increases by 1 per every
216 mm and shows the total count. For the paper with the paper length less than 216 mm, the
counter uses 216 mm as the paper length.
Transfer Belt Unit Rotation Time Counts how many hours the transfer belt unit has turned.
Transfer Belt Unit Page Count Counts how many sheets have been ejected. The counter of paper length increases by 1 per every
216 mm and shows the total count. For the paper with the paper length less than 216 mm, the
counter uses 216 mm as the paper length.
Transfer Roller Unit Counts how many sheets have been printed. The counter of paper length increases by 1 per every
216 mm and shows the total count. For the paper with the paper length less than 216 mm, the
counter uses 216 mm as the paper length.
Transfer Roller Unit Rotation Time Counts how many hours the transfer roller unit has turned.
Toner filter Not used
Imaging Unit (C) Rotation Time Counts how many hours PC drum has turned.
Imaging Unit (M) Rotation Time
Imaging Unit (Y) Rotation Time
Imaging Unit (K) Rotation Time
Imaging Unit (C) Page Count Counts how many sheets have been printed. The counter of paper length increases by 1 per every
216 mm and shows the total count. For the paper with the paper length less than 216 mm, the
counter uses 216 mm as the paper length.
Imaging Unit (M) Page Count
Imaging Unit (Y) Page Count
Imaging Unit (K) Page Count
TCR new article detection(C) Count the number of the replacement of the toner cartridge.
TCR new article detection(M)
TCR new article detection(Y)
TCR new article detection(K)
1st Feed Count Number of sheets of paper fed from tray 1.
2nd Feed Count Number of sheets of paper fed from tray 2.
