I SERVICE MODE > 16. FAX
I-107
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
000E00A6 000E01B6 000E02C6 000E03D6 00000001: 1 to 11111111:
255
[0] = HH, [1] = HL, [2] = LH,
[3] = LL
0 00000000
000E00A7 000E01B7 000E02C7 000E03D7 128 10000000
(Inhibit of) JBIG off
Rx-Function ON/
OFF
000E00A8 000E01B8 000E02C8 000E03D8 7-2 - - 00000000
1 JBIG off function at A3 high-
definition reception (DIS
retransmission)
0: OFF
1: ON
OFF
0 JBIG off function after JBIG
reception error
0: Enable
1: Disable
Enable
JBIG off Rx-JBIG
off time after error
000E00A9 000E01B9 000E02C9 000E03D9 7-0 Timer value after JBIG
reception error to reset JBIG
off reception (unit: min.)
(10 min. if 00000000)
10 min. 00001010
16.12.2Function setting 2
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
PBX dial tone
detection
frequency pattern
000E00AA 000E01BA 000E02CA 000E03DA 7 - - 00001000
(JP)
01010100
(US)
00010011
(EU)
6 Tone type
0: Single
1: Dual
Single (JP/EU)
Dual (US)
5 - -
4-0 PBX dial tone detection
frequency pattern reference
(*1)
400 ±100 Hz (JP)
350 ±25 Hz (Dual)
(US)
465 ±205 Hz (EU)
PBX dial tone
detection time
000E00AB 000E01BB 000E02CB 000E03DB 7-0 PBX dial tone detection time
or max. ON time value (unit:
20 ms)
1000 ms (JP/US)
520 ms (EU)
00110010
(JP/US)
00011010
(EU)
PBX dial tone ON
time min. value
000E00AC 000E01BC 000E02CC 000E03DC 7-0 PBX dial tone ON time min.
value (unit: 20 ms)
100 ms 00000101
PBX dial tone OFF
time max. value
000E00AD 000E01BD 000E02CD 000E03DD 7-0 PBX dial tone OFF time max.
value (unit: 20 ms)
400 ms 00010100
PBX dial tone OFF
time min. value
000E00AE 000E01BE 000E02CE 000E03DE 7-0 PBX dial tone OFF time min.
value (unit: 20 ms)
100 ms 00000101
PBX dial tone
waiting time
000E00AF 000E01BF 000E02CF 000E03DF 7-0 PBX dial tone waiting time or
pre-pause time (unit: sec.)
3 sec. 00000011
PBX dial tone
instantaneous
break detection
time
000E00B0 000E01C0 000E02D0 000E03E0 7-0 Instantaneous shutdown
detection time (unit: 20 ms) or
tone detection no. of times
(unit: No. of times)
60 ms 00000011
1st dial tone
detection
frequency pattern
000E00B1 000E01C1 000E02D1 000E03E1 7 - - 00001000
(JP)
01010100
(US)
00010011
(EU)
6 Tone type
0: Single
1: Dual
Single (JP/EU)
Dual (US)
5 - -
4-0 PBX dial tone detection
frequency pattern reference
(*1)
400 ±100 Hz (JP)
350 ±25 Hz (Dual)
(US)
465 ±205 Hz (EU)
1st dial tone
detection time
000E00B2 000E01C2 000E02D2 000E03E2 7-0 1st dial tone detection time or
ON time max. value (unit: 20
ms)
1000 ms (JP/US)
520 ms (EU)
00110010
(JP/US)
00011010
(EU)
1st dial tone ON
time min. value
000E00B3 000E01C3 000E02D3 000E03E3 7-0 1st dial tone ON time min.
value (unit: 20 ms)
0 ms 00000000
1st dial tone OFF
time max. value
000E00B4 000E01C4 000E02D4 000E03E4 7-0 1st dial tone OFF time max.
value (unit: 20 ms)
0 ms 00000000
1st dial tone OFF
time min. value
000E00B5 000E01C5 000E02D5 000E03E5 7-0 1st dial tone ON time min.
value (unit: 20 ms)
0 ms 00000000
Y119930-3
