d-Color MF4003/MF3303
L TROUBLESHOOTING > 3. TROUBLE CODE
L-62
3.18CD###
3.18.1CD002
Contents
Trouble type CD002: JOB RAM save error
Rank C
Trouble detection condition The error in save of job data to the memory / storage and its read error are detected.
Trouble isolation -
Relevant electrical parts • Storage board (STRGB)
• CPU board (CPUB)
• Base board (BASEB)
Procedure
1. Check STRGB for proper installation and correct as necessary.
2. Check CPUB for proper installation and correct as necessary.
3. Select [Service Mode] -> [State Confirmation] -> [Memory/Storage Adjustment] -> [Format] -> [Logical Format] and perform the function.
4. Replace STRGB.
5. Replace CPUB.
6. Replace BASEB.
3.18.2CD004, CD00F
Contents
Trouble type • CD004: Storage access error (connection failure)
• CD00F: Storage data transfer error
Rank C
Trouble detection condition • CD004: Unable to communicate between the storage and CPU board (CPUB).
• CD00F: Data transfer from the storage is faulty.
Trouble isolation -
Relevant electrical parts • Storage board (STRGB)
• CPU board (CPUB)
• Base board (BASEB)
Procedure
1. Check STRGB for proper installation and correct as necessary.
2. Check CPUB for proper installation and correct as necessary.
3. Replace STRGB.
4. Replace CPUB.
5. Replace BASEB.
3.18.3CD010
Contents
Trouble type CD010: Storage unformat
Rank C
Trouble detection condition Unformatted storage is connected.
Trouble isolation -
Relevant electrical parts • Storage board (STRGB)
• CPU board (CPUB)
• Base board (BASEB)
Procedure
1. Check STRGB for proper installation and correct as necessary.
2. Check CPUB for proper installation and correct as necessary.
3. Select [Service Mode] -> [State Confirmation] -> [Memory/Storage Adjustment] -> [Format] and perform the function.
4. Replace STRGB.
5. Replace CPUB.
6. Replace BASEB.
3.18.4CD011
Contents
Trouble type CD011: Storage out of specifications mounted
Rank C
Trouble detection condition A storage that falls outside the specifications is connected.
Trouble isolation -
Relevant electrical parts Storage board (STRGB)
Procedure
1. Check the storage specifications.
2. Replace STRGB.
Service Manual
Y119930-3
