d-Color MF4003/MF3303
I SERVICE MODE > 12. List Output
I-62
12. List Output
12.1Individual list print output
• Output the selected list data on the paper.
• You can select multiple lists. However, only items displayed on the same screen can be selected at a time.
• To be used at the end of setup or when a trouble occurs.
• The output time, day and date will also be printed.
List item Contents
Machine Management List To produce an output of a list of setting values, adjustment values, total counter values, and others.
To produce an output of a list of Software Switch Setting.
Adjustments List To output the adjustment list for machine adjustment, process adjustment, etc. in Service Mode.
Parameter List Output a nonvolatile parameter list.
Service Parameter Output a FAX Service Mode set value list.
Protocol Trace Last The facsimile protocol of the communication which was executed previously is output.
Error Output the facsimile procedure for the last error communication.
Fax Setting List Output a FAX user set value list. (Items vary depending on models.)
Fax Analysis List Following list is output.
• Parameter List
• Machine Management List
• Protocol Trace List (Error)
• Fax Setting List
• Activity Report
• Service Parameter List
NOTICE
• When performing Machine Management List output, a detail code history list will be output. This [Detail code] is set to analyze the cause of
the C-FA14 error or the C-E301 error. The refer, to send inquiries to OLI, also send the “detail code history list”.
<Procedure>
1. Load the A4S/A4 or 8 1/2 x 11S/8 1/2 x 11 plain paper to a paper source.
2. Select the List item to be output.
3. Select [1-Sided] or [2-Sided].
4. Press the Start key, which will let the machine produce the list.
NOTE
▪ If no item is selected, the Start key has no response.
12.2Batch list CSV output
• This setting only appears when the following conditions are satisfied.
• [Detail Settings] is selected under [Administrator] -> [Security] -> [USB Connection Permission setting].
• [ON] is selected under [Administrator] -> [Security] -> [USB Connection Permission setting] -> [External Memory (Service)].
• [Administrator] -> [Security] -> [Enhanced Security Mode] is set to “OFF.”
• To save various lists data into a USB memory device all together with the CSV format.
• Various list data has its file name in accordance with the following file name rule.
• [2-digit data symbol that corresponds to each list (see the following table) + [_(underscore)] + [13-digit serial number] + [6-digit date
(year, month, and day)] + [2-digit hour] + [2-digit minute].csv
• Compared to output to paper, outputting various lists data to the USB memory device can save time, paper, and toner. With the output
data, analyzing the machine statistically becomes easier.
List of all lists data
Target list Data symbol
Machine Management List S1
Adjustments List S2
Parameter List S3
Service Parameter S4
Protocol Trace List S5
Fax Setting List S6
Network Error Counter List S7
FAX Activity Report S8
Management List A1
Paper Size/Type Counter A2
Network Settings List A3
Configuration Page U1
PCL Font List U2
PS Font List U3
Meter Count C1
<Procedure>
1. Insert the USB memory device to the USB port (for user).
2. Touch [USB save] displayed in the Batch List CSV Output.
3. Press the Start key, the list data are transferred to the USB memory device.
Service Manual
Y119930-3
