d-Color MF4003/MF3303
P THEORY OF OPERATION > 7. UK-221
P-82
[3] Wireless LAN access point [4] Job received from a mobile device
(4)Wired+Wireless (Primary Mode)
• Use when the machine is connected to both a LAN environment and a wireless LAN environment.
• The LAN line is the main line, and the wireless LAN line is the sub line.
• The machine is used as a wireless LAN access point.
• During startup of the machine, perform wireless LAN communication between the machine and the mobile device (Android device, iOS
device, or devices supporting Wi-Fi) without via wireless LAN access point.
(a)Operation
• To execute a job received from a client via the LAN.
• To execute a job received from a PC connected to the LAN.
• To execute a job received from a PC connected to the wireless LAN.
• To execute a job received from a mobile device through a wireless communication.
Basic concept of connection
[1]
[3]
[2]
[2]
[1] LAN environment [2] Job received from a PC
[3] Job received from a mobile device - -
(5)Wired+Wireless (Wi-Fi Direct)
• This mode performs same control as that with Wired+Wireless (Primary Mode).
• When connected to devices supporting Wi-Fi Direct authentication, connection without settings of SSID and password is enabled.
7.2.3Operation on ErP Auto Power Off mode
• On ErP Auto Power Off mode, the sub power supply turns off, so that the power consumption is controlled. Touching the power key to start
the main body.
• When the main unit on which the upgrade kit is not installed, is switched to ErP Auto Power Off mode, the operations such as receiving
data, receiving fax, reading original, printing and so on cannot be executed.
• When the upgrade kit is installed, ErP Auto Power Off mode can be released remotely (by starting up the main body).
[Administrator] -> [Network] -> [Wireless Network Setting]
Diagram of standby state in "ErP Auto Off mode" of the main body
[2]
[2]
[4]
[3]
[1]
[1] LAN environment [2] Print job
[3] Client (PC) [4] Main body (on standby in ErP Auto Power Off mode)
Service Manual
Y119930-3
