C PRODUCT OUTLINE > 2. OVERALL COMPOSITION
C-13
d-Color MF4003/MF3303
2.2Section configuration
[9]
[3]
[10]
[13]
[11]
[12]
[8]
[4]
[5]
[6]
[7]
[1]
[2]
[1] Auto document feed section [2] Scanner section
[3] Paper exit/reverse section [4] Duplex section
[5] Fusing section [6] 2nd transfer section
[7] Registration section [8] Paper feed section (Manual bypass tray)
[9] Paper feed section [10] Write section (PH section)
[11] Imaging unit [12] 1st transfer section
[13] Toner supply section - -
2.3Paper path
Main body + PF-P20 + PF-P20 / Main body + PF-P21 + PF-P21
• List of drive rollers and sensors in the paper path
Y119930-3
Service Manual
