d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-90
CED
DIS
DCS TCF PIX PMC
PMC: Post Message Command
TIMER2
Setting item Contents Setting value Default setting
EOL-EOL To set the transmission time between EOLs. (*) 4.0 to 25.5 s
(Step: 0.5 s)
13.0 s
CFR-PIXWAIT Sets the waiting time from CFR is sent to the image signals are received.
Radio fax on boats occasionally requires more than 6 sec.
6.0 to 25.5 s
(Step: 0.5 s)
6.0 s
EOM-PIXWAIT Waiting time to receive PIX before sending DIS when EOM is used.
Some fax machines sends PIX without returning to Phase B in spite of EDM.
5.5 to 25.5 s
(Step: 0.5 s)
5.5 s
JM WAIT Time to continue outputting CM until receiving JM. 6.0 to 25.5 s
(Step: 0.5 s)
9.0 s
• *: EOL-EOL
EOL
1 line data
EOL
1 line data
Others
Setting item Contents Setting value Default setting
ECM Function Set whether or not to cancel reception ECM (error correction mode). ON
○
OFF
Frame Size at ECM
TX
To set the frame size at ECM transmission. 64
256
○
Cording Ability To set the coding ability.
Effective to both sending and reception.
MH
MH/MR
MH/MR/MMR
MH/MR/MMR/JBIG
○
16.7List Output
NOTE
▪ This setting is displayed only for “Line1.”
Report Addition Information
• To set whether or not to add the diagnosis code or dial number to the communication journal.
Setting value Contents Default setting
Diagnosis Code The diagnosis code is printed on the communication journal.
Dial Number The dial number is printed on the communication journal.
OFF Do not apply diagnosis codes and dial numbers.
○
TX Result Report
• To set whether or not to add image to the transmission result report.
• Even if set to “With image” images are not attached at the time of the quick memory transmission and the manual transmission.
Setting value Default setting
With image
○
Without image
Protocol Trace Auto Output
• To set the timing for the protocol trace auto output.
Setting value Default setting
Always
Error
OFF
○
16.8Function Parameter
Function parameters can be set through addressing.
NOTE
▪ To change the value in this address parameter list, comply with the telephone line regulation for each country.
▪ Depending on values that have been changed, compliance with the phone line standards of other countries may not be obtained.
To Next Page
