Error
code
Catego
ry
Contents of error How to correct Installation position
(Service Mode -> [FAX] -> [Line #])
Details can be checked with the record which is made by
the monitor speaker or telephone line.
2. Possibility of line defect -
T89 Sendin
g
(control
unit)
When the control unit is
connected, a capacity
shortage occurs during
communication
(To be determined
before start of
communication when
using a coin vendor)
Check the remaining capacity of the control unit. -
9.21T9#
Error
code
Catego
ry
Contents of error How to correct Installation position
(Service Mode -> [FAX] -> [Line #])
T90 Sendin
g (line
selectio
n)
Data may have been
transmitted with no line
specified when "No" is
selected for TX-Line
Auto Switch Setting.
Specify the line to be used to send. -
T91 Data may have been
transmitted with an
illegal line specified.
Change the line specification of the abbreviated
registration.
(Since the abbreviated registration has been imported with
an uninstalled line specified, the abbreviated registration
must be modified.)
-
T95 Recepti
on
Detected short
disconnection (line
disconnection) during
reception
Check for any telephone line connection error.
A breakage on underfloor wiring may be a possible cause.
-
9.22R0#
Error
code
Catego
ry
Contents of error How to correct Installation position
(Service Mode -> [FAX] -> [Line #])
R00 Recepti
on
(Ph.B)
Unable to detect fax
signal (CNG/DCS) from
the remote station by the
time of T1 timeout
1. Set the Receive Signal Detection Mode to No. of Times. [Network] -> [Network Setting 1] ->
Receive Signal Detection Mode
2. Set the 1300Hz Detection setting to OFF if possible.
(Fax destination: Japan only)
[Network] -> [Network Setting 2] ->
1300Hz Detection
3. For 1300Hz Detection (JP), connect the ground for the
MFP/TA/PBX. (Fax destination: Japan only)
-
4. Change the setting of 1300Hz detection frequency. (Fax
destination: Japan only)
[Function Parameter]: 000E0051
bit1-0: 00 -> 01
5. Turn ON the monitor speaker, and check if the fax signal
from the remote station can be heard. If cannot, it is judged
as a wrong number.
-
6. Change the lowest reception sensitivity to -43 dBm.
Change the signal transmission level to -15 dBm.
• [Modem/NCU] -> [Level] -> CD/
SED ON Level
• [Modem/NCU] -> [TxATT] -> PIX
TxATT, TONE/Procedure Signal
TxATT, CED/ANSam TxATT
7. Extend T1 timer.
Extend the response waiting time. (only for amount of
extended T1 timer)
• Increase by +10 seconds.
* If no effect is obtained, return the setting.
• [Communication] -> [TIMER1] ->
T1
• [Network] -> [Network Setting 2] -
> Response Waiting Time
8. Extend the DIS retransmission interval. [Function Parameter]: 000E0053 -> 4.5
sec (0x2D=00101101)
R01 Mixed
size
recepti
on
(Ph.B')
Unable to detect the
DCS (reception ability
signal) from the remote
station by T1 timeout
after received the
change instructions
(PPS-EOM) of original
size or resolution
1. Change the lowest reception sensitivity to -43 dBm.
Change the signal transmission level to -15 dBm.
• [Modem/NCU] -> [Level] -> CD/
SED ON Level
• [Modem/NCU] -> [TxATT] -> PIX
TxATT, TONE/Procedure Signal
TxATT, CED/ANSam TxATT
2. Extend T1 timer.
Extend the response waiting time. (only for amount of
extended T1 timer)
• Increase by +10 seconds.
* If no effect is obtained, return the setting.
[Communication] -> [TIMER1] -> T1
To Next Page
