L TROUBLESHOOTING > 1. JAM CODE
L-9
• Paper exit sensor (PS13)
• Base board (BASEB)
Procedure
Step Action Control signal Location of electrical component
1 Initial check items - -
2 PS10 I/O check, sensor check BASEB CN23E-9 (ON) 9-K
3 PS13 I/O check, sensor check BASEB CN16E-3 (ON) 11-K
4 M3 load check
• Check code: 45
• Multi code: 1, 2, 3
BASEB CN17E-6 to 10 1-C
5 Replace BASEB. - -
1.86#-##
1.8.166-02
Contents
JAM type Misfeed at DF document feed section
JAM code 66-02
JAM detection timing 66-02 The after separate sensor (PS16) is not turned ON even after the lapse of a given period of time
after the document main motor (M8) has turned ON.
- Paper jam of a sheet of paper left at the DF document feed section results, if the after separate
sensor (PS16) is turned ON when the main power switch is turned ON, a door is opened and
closed, or a misfeed or malfunction is reset.
Misfeed processing
location
Left cover
Relevant parts • Document main motor (M8)
• Document paper feed clutch (CL8)
• After separate sensor (PS16)
• DF control board (DFCB)
Procedure
Step Action Control signal Location of electrical component
1 Initial check items - -
2 PS16 I/O check, sensor check DFCB CN3-2 (ON) 21-P
3 CL8 load check
• Check code: 60
• Multi code: 145
DFCB CN4-2 (ON) 21-X
4 M8 load check
• Check code: 60
• Multi code: 1, 5
DFCB CN5-1 to 4 21-X
5 Replace DFCB. - -
1.8.266-13, 66-33
Contents
JAM type Misfeed at DF document transport section
JAM code 66-13, 66-33
JAM detection timing 66-13 The document registration sensor (PS17) is not turned ON (unblocked) even after the lapse of a
given period of time after the leading edge of the paper has turned ON the after separate sensor
(PS16).
66-33 The document before read sensor (PS18) is not turned ON even after the lapse of a given period of
time after the leading edge of the paper has turned ON (unblocked) the document registration
sensor (PS17).
- Paper jam of a sheet of paper left at the DF document transport section results, if the document
registration sensor (PS17) is turned ON (unblocked) when the main power switch is turned ON, a
door is opened and closed, or a misfeed or malfunction is reset.
Misfeed processing
location
Left cover
Relevant parts • Document main motor (M8)
• Document paper feed clutch (CL8)
• Document registration clutch (CL9)
• After separate sensor (PS16)
• Document registration sensor (PS17)
• Document before read sensor (PS18)
• DF control board (DFCB)
Y119930-3
