I SERVICE MODE > 8. CS Remote
I-32
d-Color MF4003/MF3303
Functions
Bit Functions Setting value Description
0 1
7 Timer 2
Dial request completed -> CONNECT reception
0000 0000 0 sec
6 0000 0001 1 sec
5 : :
4 0100 0000 64 sec
3 : :
2 1111 1110 254 sec
1 1111 1111 255 sec
0
8.2.14SW No. 14
Default
Setting value Bit
7 6 5 4 3 2 1 0
Bit Assignment 0 0 1 0 0 0 0 0
HEX
Assignment
20
Functions
Bit Functions Setting value Description
0 1
7 Timer 4
Line connection -> Start request telegram
delivery
0000 0000 0 msec
6 0000 0001 100 msec
5 : :
4 0010 0000 3,200 msec
3 : :
2 1111 1110 25,400 msec
1 1111 1111 25,500 msec
0
8.2.15SW No. 15
Default
Setting value Bit
7 6 5 4 3 2 1 0
Bit Assignment 0 0 0 1 1 1 1 0
HEX
Assignment
1E
Functions
Bit Functions Setting value Description
0 1
7 Timer 5
Wait time for other side’s response
0000 0000 0 sec
6 0000 0001 1 sec
5 : :
4 0001 1110 30 sec
3 : :
2 1111 1110 254 sec
1 1111 1111 255 sec
0
8.2.16SW No. 18
Default
Setting value Bit
7 6 5 4 3 2 1 0
Bit Assignment 0 0 0 0 0 0 0 1
HEX
Assignment
01
Service Manual
Y119930-3
