d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-114
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
00000000
(US/EU)
No. of CAR signal
detection times
000E0101 000E0211 000E0321 000E0431 7-0 CAR (information receiving
terminal start signal)
detection no. of times (unit:
No. of times)
1 time (JP)
0 time (US/EU)
00000001
(JP)
00000000
(US/EU)
Caller ID signal
waiting time
000E0102 000E0212 000E0322 000E0432 7-0 ID waiting time after Caller ID/
DIAL-IN primary response
(unit: 1000 ms)
5000 ms (JP)
0 ms (US/EU)
00000101
(JP)
00000000
(US/EU)
Remote reception
password entry
waiting time
000E0103 000E0213 000E0323 000E0433 7-0 Password signal (DTMF)
detection waiting time (unit:
100 ms)
2000 ms 00010100
16.12.5Function setting 5
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
Normal/number
display automatic
line distinction
function
000E0104 000E0214 000E0324 000E0434 7 Automatic judgment function
0: OFF
1: ON
ON (JP)
OFF (US/EU)
10000011
(JP)
00000000
(US/EU)
6-4 - -
3-0 V23 signal detection waiting
time when judged (unit: sec.)
3 sec. (JP)
0 sec. (US/EU)
Monitor speaker
(Transmission
signal sound)
000E0105 000E0215 000E0325 000E0435 7 PB tone monitoring at the
time of offhook
×
00000011
6-5 Monitor speaker in
communication
00: OFF
01: Up to DIS
10: Up to DIS + RBT
transmissions
11: ON
OFF
4-0 Speaker volume
00000: 0 to 01000: 8
3
Numeric ID [20] 000E0106 -
000E0119
000E0216 -
000E0229
000E0326 -
000E0339
000E0436 -
000E0449
7 -0 ASCII [20]
When ID is less than 20
digits, justify to the left and
insert space at the top. (No
NULL terminator)
0x20 00100000
PBX connection
mode
000E011A 000E022A 000E033A 000E044A 7-4 - - 00001111
3-0 PBX call
0000: Keypad 0 to 1001:
Keypad 9
1111: PBX unconnected
PBX unconnected
Protocol monitor 000E011B 000E022B 000E033B 000E044B 7-6 - - 00000000
5 TEL/FAX switching RBT
monitor sound
0: OFF
1: ON
OFF
4 Inhibit the speaker to sound
when off-hook key is pressed
0: Not inhibit
1: Inhibit
Not inhibit
3-0 - -
Reception function
(disable)
000E011C 000E022C 000E033C 000E044C 7 - - 00111111
6 Auto transmission not
available (Line 1 only)
0: Enable
1: Disable (Manual RX)
Enable
5 Name display
0: Not inhibit
1: Inhibit
Inhibit
4 Compulsory memory RX
0: Not inhibit
1: Inhibit
Inhibit
Service Manual
Y119930-3
