d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-113
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
1st/2nd DT
detection
parameter
000E00F3 000E0203 000E0313 000E0423 7-4 - - 00000000
3 At 2nd DT detection DP
dialing only
×
2-1 - -
0 1st DT2 type
×
Tone detection 000E00F4 000E0204 000E0314 000E0424 7-6 - - 00010001
(JP/US)
00000001
(EU)
5 1300 Hz
0: No
1: Yes
No
4 Busy Tone
0: No
1: Yes
Yes (JP/US)
No (EU)
3 PBX DT
0: No
1: Yes
No
2 3rd DT
0: No
1: Yes
No
1 2nd DT
0: No
1: Yes
No
0 1st DT
0: No
1: Yes
Yes
No. of busy tone
detection times
000E00F5 000E0205 000E0315 000E0425 7-0 No. of busy tone detection
times
2 times (JP/US)
0 time (EU)
00000010
(JP/US)
00000000
(EU)
No. of RING
detection times
000E00F6 000E0206 000E0316 000E0426 7-0 No. of RING detection times
(unit: No. of times)
2 times 00000010
RING detection
time
000E00F7 000E0207 000E0317 000E0427 7-0 RING detection time (unit:
sec.)
6 sec. 00000110
Remote station
response waiting
time
000E00F8 000E0208 000E0318 000E0428 7-0 Remote station response
waiting time at calling (unit:
sec.)
55 sec. 00110111
Answering
machine function
000E00F9 000E0209 000E0319 000E0429 7-5 Answering machine CNG
detection time (unit: 10 sec.)
001: 10 sec. to 111: 70 sec.
30 sec. 01100100
4 Answer mode
0: OFF
1: ON
OFF
3-0 Answering machine DC-
LOOP detection time (unit: 5
sec.)
0001: 5 sec. to 1111: 75 sec.
20 sec.
Remote reception
password
(Line 1 only
available)
000E00FA 000E020A 000E031A 000E042A 7-0 ASCII [2] 0x2a 00101010
000E00FB 000E020B 000E031B 000E042B 0x20 00100000
RBT transmission
time
000E00FC 000E020C 000E031C 000E042C 7-0 RingBackTone signal
transmission time (unit: 1000
ms)
20000 ms 00010100
CAR signal ON
time max. value
000E00FD 000E020D 000E031D 000E042D 7-0 CAR ON time max. value
(unit: 20 ms)
800 ms (JP)
0 ms (US/EU)
00101000
(JP)
00000000
(US/EU)
CAR signal ON
time min. value
000E00FE 000E020E 000E031E 000E042E 7-0 CAR ON time min. value
(unit: 20 ms)
200 ms (JP)
0 ms (US/EU)
00001010
(JP)
00000000
(US/EU)
CAR signal OFF
time max. value
000E00FF 000E020F 000E031F 000E042F 7-0 CAR OFF time max. value
(unit: 20 ms)
800 ms (JP)
0 ms (US/EU)
00101000
(JP)
00000000
(US/EU)
CAR signal OFF
time min. value
000E0100 000E0210 000E0320 000E0430 7-0 CAR OFF time min. value
(unit: 20 ms)
200 ms (JP)
0 ms (US/EU)
00001010
(JP)
Y119930-3
Service Manual
