d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-106
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
4 7200 bps/V.17
○
3-0 - -
Starting speed in
international com
mode (V34)
000E009A 000E01AA 000E02BA 000E03CA 7 33600 bps/V.34
×
00100000
6 31200 bps/V.34
×
5 28800 bps/V.34
○
4 26400 bps/V.34
×
3 24000 bps/V.34
×
2 21600 bps/V.34
×
1 19200 bps/V.34
×
0 16800 bps/V.34
×
CD OFF timer 000E009B 000E01AB 000E02BB 000E03CB 7-0 CD OFF timer (unit: 100 ms) 2000 ms 00010100
CD ON integration
time
000E009C 000E01AC 000E02BC 000E03CC 7-0 CD ON integration time (unit:
100 ms)
600 ms 00000110
Max. allowable
symbol speed
000E009D 000E01AD 000E02BD 000E03CD 7 V34 control ch data rate
0: 1200
1: 2400
1200 00000101
6-4 - -
3-0 Max. allowable symbol speed
0000:2400
0001: Reserved
0010: 2800
0011: 3000
0100: 3200
0101: 3429
3429
V34 primary
channel fallback
000E009E 000E01AE 000E02BE 000E03CE 7-0 No. of frame errors subjected
to fallback
3 00000011
V34 off Rx-V34 off
time after error
000E00A0 000E01B0 000E02C0 000E03D0 7-0 Timer value after V.34
reception error used to reset
V34 off reception (unit: min.)
(Valid only when transmission
side cannot be specified)
10 min. 00001010
V34 off Rx-V17 OK
Rx times to reset
V34 off Rx
000E00A1 000E01B1 000E02C1 000E03D1 7-0 No. of continuous success of
V17 receptions used to reset
V34 off reception after V.34
reception error (unit: No. of
times)
(Valid only when transmission
side can be specified with
Caller ID)
10 times 00001010
(Inhibit of) V34 off
Rx-Function ON/
OFF
000E00A2 000E01B2 000E02C2 000E03D2 7 V.34 off function for manual
reception (Line 1 only)
0: Enable
1: Disable
Enable 00000000
(JP)
00000010
(US/EU)
6-2 - -
1 V.34 OFF reset mode = No.
of successful consecutive
V.17 reception times (ID
specified)
0: Enabled
1: Disabled
Enabled (JP)
Disabled (US/EU)
0 V.34 OFF reset mode = time
(ID cannot be specified)
0: Enabled
1: Disabled
Enabled
JBIG parameter 000E00A3 000E01B3 000E02C3 000E03D3 7-2 - - 00000001
1 Use of following FP JBIG
option LO size at reduction
0: No
1: Yes
No
0 JBIG optional LO capacity
0: No
1: Yes
Yes
JBIG LO size 000E00A4 000E01B4 000E02C4 000E03D4 7-0 JBIG optional LO size used
for reduction
0 00000000
000E00A5 000E01B5 000E02C5 000E03D5 0 00000000
Service Manual
Y119930-3
