d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-105
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
3-2 - -
1-0 Cable EQL parameter
selection
00: 1.8 km
01: 3.6 km
10: 7.2 km
11: NTT4
1.8 km
V34 point number 000E0094 000E01A4 000E02B4 000E03C4 7-2 - - 00000000
1-0 V34 Point
00: Auto
01: 16-point
10: 4-point
Auto
TEL/FAX switching
(For Line 1 and
Japan model only)
000E0095 000E01A5 000E02B5 000E03C5 7 Time from vocal response to
RBT transmission (CNG
detection waiting time 2)
0: 4 sec.
1: 2 sec.
4 sec. 00000000
6 Time from reception to voice
response transmission (CNG
detection waiting time 1)
0: 2 sec.
1: 4 sec.
2 sec.
5 TEL/FAX switching mode
0: Disabled
1: Enabled
Disabled
4 External telephone no ringing
setting
0: Disabled
1: Enabled (disconnected)
Disabled
3 TEL/FAX switching ON
response details
0: Voice response + RBT
transmission
1: RBT transmission only
Voice response +
RBT transmission
2-0 - -
Ring Back Tone
parameter
(For Line 1 and
Japan model only)
000E0096 000E01A6 000E02B6 000E03C6 7-5 RBT form
000: None
001: JP
010: US
011: GB
100: GE
101 to 111: Others
JP (JP)
US (US)
GB (EU)
00101010
(JP)
01001010
(US)
01101000
(EU)
4 CED transmitted upon TEL/
FAX switching
×
3-0 RBT transmission level (-
dBm)
0000: 0 dBm to 1111: -15
dBm
-10 dBm (JP/US)
-8 dBm (EU)
International com
mode operation
000E0097 000E01A7 000E02B7 000E03C7 7 DIS waiting frequency
0: Always once
1: Twice in overseas
communication
Always once 01000000
6 Overseas communication
0: No
1: Yes
Yes
5-0 - -
Starting speed in
international com
mode (V29
modem)
000E0098 000E01A8 000E02B8 000E03C8 7-5 - - 00000010
4 9600 bps/V.29
×
3 7200 bps/V.29
×
2 - -
1 4800 bps/V.27 ter
â—‹
0 2400 bps/V.27 ter
×
Starting speed in
international com
mode (V17 or V33
modem)
000E0099 000E01A9 000E02B9 000E03C9 7 14400 bps/V.17
×
00010000
6 12000 bps/V.17
×
5 9600 bps/V.17
×
