d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-97
Items Address Data Default
Bit Contents Setting Data
Delay timer between CED-DIS 000E0011 7-0 CED - DIS delay timer (unit: 10 ms) 80 ms 00001000
T1 timer for calling 000E0012 7-0 T1 timer for transmission (unit: 1 sec.) 35 sec. 00100011
T1 timer for called 000E0013 7-0 T1 timer for reception (unit: 1 sec.) 35 sec. 00100011
ph.C reception limited time 000E0014 7-0 Max. reception time per page (unit: min.)
00000001: 1 min. to 11111111: 255 min.
15 min. 00001111
Timer between EOLs 000E0015 7-0 EOL - EOL timer (unit: 100 ms) 13000 ms 10000010
Timer between frames 000E0016 7-0 Timer between frames (unit: sec.) 35 sec. 00100011
ANSam signal transmission time 000E0017 7-0 ANSam signal transmission time (unit: 100 ms) 4000 ms 00101000
Ci signal transmission time 000E0018 7-0 Ci signal transmission time (unit: 100 ms) 500 ms 00000101
High-speed signal transmission
waiting delay timer
000E0019 7-0 High-speed signal transmission waiting delay timer
(unit: 10 ms)
(Between CFR-PIX/MPS-PIX/CTR-PIX)
550 ms 00110111
ph.C top dummy data
transmitting time
000E001A 7-0 ph.C top dummy data transmission time (unit: 100 ms)
(Dummy data for non-ECM / Preamble at ECM)
400 ms 00000100
RTC counter 000E001B 7-3 - - 00000001
2-0 The EOL counter judged to be RTC
000: EOL*2
001: EOL*3
010: EOL*4
011: EOL*5
100: EOL*6
EOL*3
Closed area communication 000E001C 7-3 - - 00000000
2 Polling TX
×
1 Polling RX
×
0 - -
Machine password [20] 000E001D
- 000E0030
7-0 ASCII [20]
When ID is less than 20 digits, justify to the left and
insert space at the top. (No NULL terminator)
0x20 00100000
CSRC password [20] 000E0031 -
000E0044
7-0 ASCII [20]
When ID is less than 20 digits, justify to the left and
insert space at the top. (No NULL terminator)
0x20 00100000
Watch dog 000E0045 7-1 - - 00000001
0 Watch dog
0: OFF
1: ON
ON
T2 timer after CFR 000E0046 7-0 T2 timer value after CFR x100 ms 6000 ms 00111100
T2 timer after EOM 000E0047 7-0 T2 timer after EOM x100 ms 5500 ms 00110111
JIM waiting timer 000E0048 7-0 JM waiting timer value x100 ms 9000 ms 01011010
Destination 000E0049 7-0 00000000: US
00000001: Canada
00000010: Japan
00000011: Australia
00000100: New Zealand
00000101: Europe
00000110: Germany
00000111: UK
00001000: France
00001001: Switzerland
00001010: Netherlands
00001011: Belgium
00001100: Australia
00001101: Norway
00001110: Sweden
00001111: Finland
00010000: Ireland
00010001: Denmark
00010010: Italy
00010011: Spain
00010100: Portugal
00010101: Poland
00010110: South Africa
00010111: Taiwan
00011000: Saudi Arabia
00011001: China
00011010: Malaysia
00011011: Singapore
Japan (JP)
US (US)
Europe (EU)
00000010
(JP)
00000000
(US)
00000101
(EU)
Y119930-3
