d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-98
Items Address Data Default
Bit Contents Setting Data
00011100: Korea
00011101: Hong Kong
00011110: Generic (OT)
00011111: Argentina
00100000: Brazil
00100001: Vietnam
00100010: Philippines
00100011: Russia
Function when DIS signal is
created
000E004A 7-2 - - 00000001
1 Change-over of the silent interval between ANSam and
DIS (For revision T.30)
0: Silent interval of 450 ms
1: 75 ms
Silent interval of 450
ms
0 V8 capability, if available, of DIS to transmit with V.21
0: V.8 bit ON
1: V.8 bit OFF
V.8 bit OFF
Signal check at the time of F
code communication
000E004B 7-1 - - 00000000
0 Check of PWD and SID received signal in F code
communication
0: Signal checked
1: PWD and SID not distinguished
Signal checked
No. of CI signal transmission in
manual transmission
000E004C 7-0 CI signal repetitive transmission frequency when no
ANSam received after CI transmission (unit: No. of
times)
3 times 00000011
Tone detection time (PB) 000E004D 7-4 PB OFF time integration (x10 ms)
0000 to 1111 (Translated to 50 ms when the value is
"0000")
50 ms 01010101
3-0 PB ON time integration (x10 ms)
0000 to 1111 (Translated to 50 ms when the value is
"0000")
50 ms
Time for modem response
waiting timeout
000E004E 7-0 Waiting event from modem/Response waiting timeout
time (x10 sec.)
(00000000 counted as 90 sec.)
90 sec. 00000000
Continuous CRP reception
frequency resulting in an error
000E004F 7-0 Sequential CRP reception frequency resulting in error
(unit: No. of time)
(00000000 counted as 3 times)
3 times 00000000
1300 Hz line seizure parameter
detection time
000E0050 7-0 1300 Hz tone detection time for no ringing reception
(x100 ms)
2300 ms 00010111
1300 Hz tone detection
frequency pattern
000E0051 7-1 - - 00000000
0 1300 Hz tone detection frequency pattern
00: 1300 Hz ±30 Hz
01: 1300 Hz ±10 Hz
1300 Hz ±30 Hz
German specifications 000E0052 7 Custom Mode (clears the FP overwrite of the error line
relationship for EU destinations)
×
00000000
(JP/US)
00001111
(EU)
6-4 - -
3 ERR transmission (DTS sequence)
× (JP/US)
â—‹ (EU)
2 DCN reception error ignored
× (JP/US)
â—‹ (EU)
1 Line disconnected within 6 sec. after CD OFF in ph.C
× (JP/US)
â—‹ (EU)
0 Line disconnected upon reception of DIS to DTC
× (JP/US)
â—‹ (EU)
Retransmission intervals of DIS
(Auto reception)
000E0053 7-0 DIS re-transmission interval in automatic reception
(x0.1 sec.)
3 sec. 00011110
TTI for transmission 000E0054 7-2 - - 00000011
1-0 TTI in transmission TTI added
00: OFF
01: (OFF)
10: INSIDE
11: OUTSIDE
OUTSIDE
Image reduction parameter 000E0055 7-1 - - 00000000
0 Reduction parameter in main scanning direction
0: Thick line kept
1: Thick line not kept
Thick line kept
