I SERVICE MODE > 16. FAX
I-110
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
* Normal conforms to
Ringer[2] through [5] as
usual.
* For DRPD, configure the
margin time (min, max) from
the standard time (*1).
Ringer detection
frequency upper
limits
000E00C6 000E01D6 000E02E6 000E03F6 7-0 Ringer detection frequency
upper limit (unit: 1 Hz)
70 Hz 01000110
Ringer detection
frequency lower
limits
000E00C7 000E01D7 000E02E7 000E03F7 7-0 Ringer detection frequency
lower limits (unit: 1 Hz)
12 Hz 00001100
Ringer ON time
max. value
000E00C8 000E01D8 000E02E8 000E03F8 7-0 Ringer ON time max. value
(unit: 20 ms)
0 ms 00000000
Ringer ON time
min. value
000E00C9 000E01D9 000E02E9 000E03F9 7-0 Ringer ON time min. value
(unit: 20 ms)
200 ms (JP/US)
160 ms (EU)
00001010
(JP/US)
00001000
(EU)
Ringer OFF time
max. value
000E00CA 000E01DA 000E02EA 000E03FA 7-0 Ringer OFF time max. value
(unit: 100 ms)
6000 ms (JP/US)
7000 ms (EU)
00111100
(JP/US)
01000110
(EU)
Ringer OFF time
min. value
000E00CB 000E01DB 000E02EB 000E03FB 7-0 Ringer OFF time min. value
(unit: 100 ms)
200 ms (JP)
0 ms (US/EU)
00000010
(JP)
00000000
(US/EU)
DRPD ringer ON
time max. value
000E00CC 000E01DC 000E02EC 000E03FC 7-0 DRPD ringer ON time max.
value (unit: 20 ms)
180 ms 00001001
DRPD ringer ON
time min. value
000E00CD 000E01DD 000E02ED 000E03FD 7-0 DRPD ringer ON time min.
value (unit: 20 ms)
180 ms 00001001
DRPD ringer OFF
time max. value
000E00CE 000E01DE 000E02EE 000E03FE 7-0 DRPD ringer OFF time max.
value (unit: 20 ms)
180 ms 00001001
DRPD ringer OFF
time min. value
000E00CF 000E01DF 000E02EF 000E03FF 7-0 DRPD ringer OFF time min.
value (unit: 20 ms)
180 ms 00001001
DRPD max.
adjustment value
for max. OFF time
000E00D0 000E01E0 000E02F0 000E0400 7-0 DRPD max. adjustment value
for max. OFF time (unit: 100
ms)
500 ms 00000101
DRPD min.
adjustment value
for max. OFF time
000E00D1 000E01E1 000E02F1 000E0401 7-0 DRPD ringer min. adjustment
value for max. OFF time (unit:
100 ms)
500 ms 00000101
DRPD single ring
stop detection time
000E00D2 000E01E2 000E02F2 000E0402 7-0 DRPD single ring stop
detection time (unit: 100 ms)
8000 ms 01010000
DRPD double ring
stop detection time
000E00D3 000E01E3 000E02F3 000E0403 7-0 DRPD double ring stop
detection time (unit: 100 ms)
8000 ms 01010000
DRPD Triple1 ring
stop detection time
000E00D4 000E01E4 000E02F4 000E0404 7-0 DRPD Triple1 ring stop
detection time (unit: 100 ms)
8000 ms 01010000
DRPD Triple2 ring
stop detection time
000E00D5 000E01E5 000E02F5 000E0405 7-0 DRPD Triple2 ring stop
detection time (unit: 100 ms)
8000 ms 01010000
DRPD NZ-DA1 ring
stop detection time
000E00D6 000E01E6 000E02F6 000E0406 7-0 DRPD NZ-DA1 ring stop
detection time (unit: 100 ms)
6000 ms 00111100
DRPD NZ-DA2 ring
stop detection time
000E00D7 000E01E7 000E02F7 000E0407 7-0 DRPD NZ-DA2 ring stop
detection time (unit: 100 ms)
6000 ms 00111100
DRPD NZ-DA3 ring
stop detection time
000E00D8 000E01E8 000E02F8 000E0408 7-0 DRPD NZ-DA3 ring stop
detection time (unit: 100 ms)
5000 ms 00110010
DRPD NZ-DA4 ring
stop detection time
000E00D9 000E01E9 000E02F9 000E0409 7-0 DRPD NZ-DA4 ring stop
detection time (unit: 100 ms)
5000 ms 00110010
Custom 1st ringer
ON time specified
value
000E00DA 000E01EA 000E02FA 000E040A 7-0 Custom 1st ringer ON time
specified value (unit: 100 ms)
0 ms 00000000
Custom 1st ringer
OFF time specified
value
000E00DB 000E01EB 000E02FB 000E040B 7-0 Custom 1st ringer OFF time
specified value (unit: 100 ms)
0 ms 00000000
Custom 2nd ringer
ON time specified
value
000E00DC 000E01EC 000E02FC 000E040C 7-0 Custom 2nd ringer ON time
specified value (unit: 100 ms)
0 ms 00000000
Service Manual
Y119930-3
