d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-116
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
3 Single detection for V.17 or
lower during V.21 setup
0: OFF
1: ON
OFF
2 Ignore DIS for V.17 or lower
0: OFF
1: ON
OFF
1-0 - -
Over-current
protection function
with current setting
000E0129 000E0239 000E0349 000E0459 7-0 Current detection threshold
(×1 mA)
160 mA 00000000
Over-current
protection function
with voltage setting
000E012A 000E023A 000E024A 000E045A 7 - - 00000000
6-0 Voltage threshold (x1 V) 21 V
Over-current
protection function
with resistance
setting
000E012B 000E023B 000E034B 000E045B 7 - - 00000000
6-0
Voltage threshold (×10 Ω) 190 Ω
Timer for adjusting
Phase B
retransmission
interval (V.17)
000E012D 000E023D 000E034D 000E045D 7-6 Phase B re-transmission
interval at manual receiving
(available at polling
transmission)
00: 3.0 s
01: 3.5 s
10: 4.0 s
11: 4.5 s
3.0 s 00000000
5-4 Phase B re-transmission
interval at manual sending
00: 3.0 s
01: 3.5 s
10: 4.0 s
11: 4.5 s
3.0 s
3-2 Phase B re-transmission
interval at automatic receiving
(available at polling
transmission)
00: 3.0 s
01: 3.5 s
10: 4.0 s
11: 4.5 s
3.0 s
1-0 Phase B re-transmission
interval at automatic sending
00: 3.0 s
01: 3.5 s
10: 4.0 s
11: 4.5 s
3.0 s
Timer for adjusting
Phase D
retransmission
interval (V.17)
000E012E 000E023E 000E034E 000E045E 7-4 - - 00000000
3-2 Phase D re-transmission
interval at manual sending
00: 3.0 s
01: 3.5s
10: 4.0 s
11: 4.5 s
3.0 s
1-0 Phase D re-transmission
interval at automatic sending
00: 3.0 s
01: 3.5s
10: 4.0 s
11: 4.5 s
3.0 s
Conexant Modem
Function selection
000E012F 000E023F 000E034F 000E045F 7-5 - - 00000000
4 ANSam/CED detection
method
0: Determined by ATV25 only
1: Determined by ATV25 and
TONEA
Determined by
ATV25 only
3 Fix training data to normal RX
value before V.17 reception
0: No
1: Yes
Yes
