d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-103
Items Address Data Default
Bit Contents Setting Data
DialIn additional No. (telephone)
[12]
0013005D -
00130068
7-0 ASCII 11 digits + NULL 0x00 00000000
Upper limit for signal
transmission level setting
00130069 7-0 Upper limit for signal transmission level setting (-dBm) -10 dBm (JP/US)
-8 dBm (EU)
00001010
(JP/US)
00001000
(EU)
Lower limit for call termination
no. of times setting range
0013006A 7-0 Lower limit for call termination no. of times setting
range (unit: No. of times)
0 time 00000000
Upper limit for call termination
no. of times setting range
0013006B 7-0 Upper limit for call termination no. of times setting
range (unit: No. of times)
15 times 00001111
Dial method setting 0013006C 7-2 - - 00000000
(JP)
00100010
(US)
00010001
(EU)
1-0 Dial method setting
00: PB/10pps/20pps
01: PB
10: PB/10pps
11: PB/10pps/16pps
PB/10pps/20pps (JP)
PB/10pps (US)
PB (EU)
Upper limit for redial no. of times
setting range
0013006D 7-0 Upper limit for redial no. of times setting range (unit:
No. of times)
7 times (JP/EU)
1 time (US)
00000111
(JP/EU)
00000001
(US)
Upper limit for redial interval
setting range
0013006E 7-0 Upper limit for redial interval setting range (unit: min.) 1 min. 00000001
Lower limit for redial interval
setting range
0013006F 7-0 Lower limit for redial interval setting range (unit: min.) 15 min. 00001111
Telephone-related function
setting menu display (1)
00130070 7 - - 01111111
(JP)
00000000
(US/EU)
6 Remote reception
0: OFF
1: ON
ON (JP)
OFF (US/EU)
5 Dial In
0: OFF
1: ON
ON (JP)
OFF (US/EU)
4 Number display
0: OFF
1: ON
ON (JP)
OFF (US/EU)
3 Pesudo RBT form
0: OFF
1: ON
ON (JP)
OFF (US/EU)
2 Pesudo RBT transmission level
0: OFF
1: ON
ON (JP)
OFF (US/EU)
1 Connection to answering machine
0: OFF
1: ON
ON (JP)
OFF (US/EU)
0 TEL/FAX switching
0: OFF
1: ON
ON (JP)
OFF (US/EU)
Number display related function
setting
00130071 7-2 - - 00000000
1-0 Name displayed type of display at fax reception
00: No display
01: Display of number
10: Display of name
No display
Setting of lower limit for DTMF
transmission level setting range
00130072 7-0 Setting of lower limit for DTMF transmission level
setting range (-dBm)
-14 dBm (JP)
-15 dBm (US)
-9 dBm (EU)
00001110
(JP)
00001111
(US)
00001001
(EU)
Setting of upper limit for DTMF
transmission level setting range
00130073 7-0 Setting of upper limit for DTMF transmission level
setting range (-dBm)
-10 dBm (JP/US)
-5 dBm (EU)
00001010
(JP/US)
00000101
(EU)
Setting of lower limit for DTMF
H-L level difference setting
range
00130074 7-0 Setting of lower limit for DTMF H-L level difference
setting range (dB)
1 dB 00000001
Setting of upper limit for DTMF
H-L level difference setting
range
00130075 7-0 Setting of upper limit for DTMF H-L level difference
setting range (dB)
4 dB 00000100
Y119930-3
Service Manual
