P THEORY OF OPERATION > 8. FK-517
P-87
bit Function Contents Default
1,1=Invalid
19 Recording paper length ability bit 19, 20
0,0=A4
0,1=Unlimited
1,0=B4
1,1=Invalid
0
20 1
21 Minimum scan line time ability Refer to *2. 1
22 0
23 0
24 Expansion field 1
• *2: Minimum scan line time ability (bit 21, 22 and 23)
21 22 23 Contents
0 0 0 3.85 l/mm --- 20 ms 7.7 l/mm --- 20 ms
0 0 1 3.85 l/mm --- 40 ms 7.7 l/mm --- 40 ms
0 1 0 3.85 l/mm --- 10 ms 7.7 l/mm --- 10 ms
0 1 1 3.85 l/mm --- 10 ms 7.7 l/mm --- 5 ms
1 0 0 3.85 l/mm --- 5 ms 7.7 l/mm --- 5 ms
1 0 1 3.85 l/mm --- 40 ms 7.7 l/mm --- 20 ms
1 1 0 3.85 l/mm --- 20 ms 7.7 l/mm --- 10 ms
1 1 1 3.85 l/mm --- 0 ms 7.7 l/mm --- 0 ms
(d)Octet 7
bit Function Contents Default
25 Reserved 0
26 Non-compression mode 0
27 Error correction mode (ECM) ability 1: with ECM
0: without ECM
1
28 0: fixed 0
29 Reserved 0
30 Reserved 0
31 T.6 coding (MMR) ability 1: with MMR
0: without MMR
1
32 Expansion field 1
(e)Octet 8
bit Function Contents Default
33 Field not valid 0
34 Multi-selective polling 1: Ability
0: No ability
0
35 Polled sub-address 0
36 T.43 coding ability 0
37 Plain Interleave 0
38 32K ADPCM voice coding 0
39 Reserved 0
40 Expansion field 1
(f)Octet 9
bit Function Contents Default
41 R8×15.4 l/mm 1
42 300×300 pels/25.4 mm 0
43 R16×15.4 l/mm and/or 400×400 pels/25.4 mm 1
44 inch ability 1
45 mm ability 1
46 Minimum scan line time ability of high resolution 0: T15.4=T7.7
1: T15.4=1/2T7.7
0
47 Selective polling 1
48 Expansion field 1
Y119930-3
