d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-85
Setting item Contents Setting value Default setting
Control CH Speed A bit speed of the control channel.
The negotiation of 2400/1200 is performed in the V.34 start-up
procedure.
1200 bps
○
2400 bps
Max. SYMB Speed Maximum modulation speed (baud rate) of V.34
• 3429 SYMB: 3429 33.6 k to 4.8 k
• 3200 SYMB: 3200 31.2 k to 2.4 k
• 3000 SYMB: 3000 28.8 k to 2.4 k
• 2800 SYMB: 2800
• 2400 SYMB: 2400
The modulation speed of both sending and receiving change
by change of setting.
The upper limit value of V.34 maximum bit speed is
determined.
Normally you do not need to change the value. In case that a
V.34 error frequently occurs, you can attempt to set up 3000
SYMB and decrease the symbol rate, for instance.
2400 SYMB
2800 SYMB
3000 SYMB
3200 SYMB
3429 SYMB
○
V34 Point Number Select the optimal Eye Pattern in accordance with the line state
obtained from V.34 transmission training.
Auto
○
16Point
4Point
V17 Send Max Speed
Setting item Contents Setting value Default setting
TX Max. Speed To set the max. speed for transmission. V17-14400 bps
○
V17-12000bps
V17-9600bps
V17-7200bps
V29-9600bps
V29-7200bps
V27-4800bps
V27-2400bps
RX Max. Speed To set the max. speed for reception. V17-14400 bps
○
V29-9600bps
V27-4800bps
TxATT
Setting item Contents Procedure
PIX TxATT To set the output level of PIX TxATT.
Directly sets modem. There are no external attenuator.
The setting value are different depending on the
country.
TONE/Procedure Signal
TxATT
To set the output level of TONE/Procedure Signal TxATT.
Directly sets modem. There are no external attenuator.
CED/ANSam TxATT To set the output level of CED/ANSam TxATT.
Directly sets modem. There are no external attenuator.
DTMF TxATT To set the output level of DTMF TxATT.
Directly sets modem. There are no external attenuator.
Level
Setting item Contents Setting value Default setting
CD/SED ON Level To set reception signal sensitivity level.
SED is not used.
-48 to -33 dBm
(Step: 5 dBm)
-48 dBm
DTMF H-L Level
Difference
To set DTMF H-L level difference. 1.0 to 4.0 dB
(Step: 0.5 dB)
2.0 dB
Cable EQL
Setting item Contents Setting value Default setting
Send/Rec. To correct the delay characteristics of the communication line. 0 Km
○
1.8 Km
3.6 Km
7.2 Km
Y119930-3
Service Manual
