Olivetti d-Color MF4003 User Manual

d-Color MF4003/MF3303
I SERVICE MODE > 16. FAX
I-121
Items Address Data Default
Line 1 Line 2 Line 3 Line 4 Bit Contents Setting Data
0 V.34-216
○
Transmission
MSLT instruction
0010000B 0010002B 0010004B 0010006B 7-0 T3.85 or 200*100 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
0010000C 0010002C 0010004C 0010006C 7-0 T7.7 or 200*200 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
0010000D 0010002D 0010004D 0010006D 7-0 T11.55 or 300*300 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
0010000E 0010002E 0010004E 0010006E 7-0 T15.4 or 400*400 dpi or
600*600 dpi (ms)
00000000: 0 ms to
00101000: 40 ms
5 ms 00000101
Transmission ECM
instruction
0010000F 0010002F 0010004F 0010006F 7-2 - - 00000001
1 ECM transmission frame size
0: 256
1: 64
256
0 ECM transmission instruction
0: OFF
1: ON
ON
Transmission
protocol instruction
00100010 00100030 00100050 00100070 7-6 - - 00010001
5 FAX-CSRC (Line 1 only)
×
4 V.8/V.34
○
3 DIAG (Line 1 only)
×
2-1 - -
0 G3S
○
Transmission
option frame
instruction
00100011 00100031 00100051 00100071 7-5 - - 00000000
4 (BFT)
×
3 (BTM)
×
2 PWD
×
1 (SEP)
×
0 SUB
×
Y119930-3
Service Manual
