d-Color MF4003/MF3303
M PARTS/CONNECTOR LAYOUT DRAWING > 1. PARTS LAYOUT DRAWING
M-2
[3] Machine condition monitor board/Fr (MCMB/Fr) [4] Front door sensor (PS1)
[5] Front door switch (SW2) [6] Right door sensor (PS2)
[7] Right door switch (SW5) [8] USB hub board (USBHB) *1
[9] NFC board (NFCB) [10] Main power switch (SW1)
[11] Wireless LAN board (WLANB) *2 [12] Waste toner bottle set sensor (PS6)
[13] Waste toner near full sensor (PS15) [14] Fax speaker (SP1)
[15] TCR sensor/Y (TCRS/Y) [16] TCR sensor/M (TCRS/M)
[17] TCR sensor/C (TCRS/C) [18] TCR sensor/K (TCRS/K)
*1: Option
*2: Standard equipment only for North America models.
(2)Load
[1]
[2]
[1] Toner supply motor/YM (M4) [2] Toner supply motor/CK (M5)
Service Manual
Y119930-3
