d-Color MF4003/MF3303
M PARTS/CONNECTOR LAYOUT DRAWING > 2. CONNECTOR LAYOUT
DRAWING
M-11
CN1 (25pin)
(9)DC power supply (DCPS)
CN2
(3pin)
CN1
(2pin)
CN4 (8pin)CN3 (3pin)
CN5
(4pin)
CN6 (8pin)
(10)DF control board (DFCB)
Y119930-3
