d-Color MF4003/MF3303
P THEORY OF OPERATION > 8. FK-517
P-90
bit Function Contents Default
126 0
127 sYCC-JPEG coding 0
• *3: T.89 (Application profile for ITU-T T.88)
124 125 126 Contents
0 0 0 Not used
0 0 1 Profile 1
0 1 0 Profile 2
0 1 1 Profile 3
1 0 0 Profile 2 and 3
1 0 1 Reserved
1 1 0 Reserved
1 1 1 Reserved
(2)FIF data configuration list (DCS)
(a)Octet 4
bit Function Contents Default
1 T.37 Internet fax (Simple mode) 0
2 Reserved 0
3 T.38 real time Internet fax 0
4 Third generation mobile network 0
5 Reserved 0
6 Invalid 0
7 Invalid 0
8 Reserved 0
(b)Octet 5
bit Function Contents Default
9 0: fixed 0
10 Reception command 1
11 Transmission speed instruction Refer to *1. @
12 @
13 @
14 @
15 R8×7.7 l/mm or 200×200 pels/25.4 mm 1: 7.7 l/mm
0: 3.85 l/mm
@
16 Two-dimensional coding instruction 1: MR
0: MH
@
• @: Changes to 0 or 1 according to a status of devices.
• *1: Transmission speed appointment (bit 11, 12, 13 and 14)
11 12 13 14 Contents
0 0 0 0 24/V27 ter
0 1 0 0 48/V27 ter
1 0 0 0 96/V29
1 1 0 0 72/V29
0 0 0 1 144/V17
0 1 0 1 120/V17
1 0 0 1 96/V17
1 1 0 1 72/V17
(c)Octet 6
bit Function Contents Default
17 Recording paper width instruction bit 17, 18
0,0=A4
0,1=A3
1,0=B4
1,1=Invalid
@
18 @
19 Recording paper length instruction bit 19, 20
0,0=A4
0,1=Unlimited
@
20 @
