P THEORY OF OPERATION > 8. FK-517
P-92
bit Function Contents Default
50 Password (SID) transmission @
51 0: fixed 0
52 Reserved 0
53 BFT transfer @
54 DTM transfer 0
55 EDI transfer 0
56 Expansion field @
• @: Changes to 0 or 1 according to a status of devices.
(h)Octet 11
bit Function Contents Default
57 BTM transfer 0
58 Reserved 0
59 0: fixed 0
60 Character mode 0
61 Reserved 0
62 Mixed mode 0
63 Reserved 0
64 Expansion field @
• @: Changes to 0 or 1 according to a status of devices.
(i)Octet 12
bit Function Contents Default
65 Processible mode (T.505) 0
66 Digital network ability 0
67 Full-duplex communication instruction 1: Full-duplex
0: Half-duplex
0
68 JPEG coding 0
69 Full color mode 0
70 Default Huffman table use 0
71 12 bits / pixel component 0
72 Expansion field @
• @: Changes to 0 or 1 according to a status of devices.
(j)Octet 13
bit Function Contents Default
73 No sub sampling (1:1:1) 0
74 Custom illuminance 0
75 Custom gamut range 0
76 North America Letter (215.9 x 279.4) 0
77 North America Legal (215.9 x 355.6) 0
78 Single progression sequential coding (T.85) basic @
79 Single progression sequential coding (T.85) optional
LO
@
80 Expansion field @
• @: Changes to 0 or 1 according to a status of devices.
(k)Octet 14
bit Function Contents Default
81 HKM key management selected 0
82 RSA key management selected 0
83 Override mode selected 0
84 HFX40 cipher selected 0
85 Alternative cipher number 2 selected 0
86 Alternative cipher number 3 selected 0
87 HFX40-I hashing selected 0
88 Expansion field @
• @: Changes to 0 or 1 according to a status of devices.
Service Manual
