d-Color MF4003/MF3303
P THEORY OF OPERATION > 8. FK-517
P-104
(1)Signal format
(a)Contents of signals
Item / Signal Name SUB/SEP SID
Characters 0 to 9 only (* and # must not be used.) • 0 to 9
• *
• #
Contents Box No. Password
No. of digits Arbitrary between 1 and 20
Space between digits Prohibited
Others Impossible to designate more than one box
(b)FIF (SUB/SEP/SID) common
• The last digit is left-justified. The remaining are filled with space (0x20)
eg.) 12345
35 34 33 32
F A C FCF FIF FCS F
20 20 20 20 20 20 20 20 20 20 20 20 20 20 2031
(c)DIS/DTC/DCS bit condition
Bit No. Meaning DIS/DTC DCS
47 Selective polling ability • DIS = ON when SEP reception is possible
• DTC = ON when SEP is transmitted
0: fixed
49 Sub address ability / function ON when SUB reception is possible ON when SUB transmission is possible
50 Password / sender ID • DIS = ON when SID reception is possible
• DTC = ON when SID is transmitted
ON when SID is transmitted
(2)F-code confidential transmission
Remote entry
Print
Confidential
Box
F-code compliant machine
Box No.
Box No.
F-code compliant center machine
SS
SS
UU
UU
BB
BB
//
//
((
((
SS
SS
II
II
DD
D
))
))
(2)
(1)
(3)
(4)
1. The confidential box is registered in the center machine.
• Registration of confidential box No. and name
• Registration of communication password
• Registration of box password
2. Transmission operation on the transmitting side
• Specification of confidential box No.
3. Reception in the center machine
• Automatic output of confidential communication report
4. Printing in the center machine
• Output by entering an access protect No.
(a)BOX specifications
Confidential box No. • Represented by a nine digit number. Operationally between 1 and 999999999.
• You can not open the same box number as the bulletin board No. which has been already
opened.
Communication password Possible to use.
Confidential BOX name Possible to resister up to 20 characters.
Erased at printing Erased on every page after output.
Box password Represented by eight digit number between 00000000 and 99999999.
No. of files in confidential box 100 files at the maximum including bulletin board.
Service Manual
Y119930-3
